Home > Manufacturing & Processing Machinery > Agricultural Machinery > Slaughtering Equipment > Chickens Slaughtering Processing Line 500 B/hour Quality Choice
Chickens Slaughtering Processing Line 500 B/hour Quality Choice
US$ 550,000 - 650,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Poultry
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Poultry Slaughter Machine and EquipmentUS$ 550,000 - 650,000MOQ: 1 Set -
1500birds/h Halal Poultry Slaughtering MachineUS$ 550,000 - 650,000MOQ: 1 Set
-
300-500 Chickens Slaughtering LineUS$ 550,000 - 650,000MOQ: 1 Set
-
Poultry Farm EquipmentUS$ 550,000 - 650,000MOQ: 1 Set
-
Cold Water and Ice Filled Poultry Bird Precooling MachineUS$ 1,000 - 10,000MOQ: 1 Set
Condition
New
Application
Poultry
Place of Origin
Shandong, China
Brand Name
ONESTOP
Model Number
N/M
Voltage
220V/380V
Power(W)
1500W
Dimension(L*W*H)
Chicken Slaughtering Machine
Weight
1500kg
Certification
ISO
After-sales Service Provided
Engineers available to service machinery overseas
1000Chickens/h Slaughter and Parting Line
| 1000 Chickens per hour Slaughter&Cutting Line Equipment List | |||||
| No. | Items | Model | Unit | Quantity | Remarks |
| I. Slaughter/Scald/Defeather Section | |||||
| 1 | Hanging conveyor for slaughter | L=88m | set | 1 | Hook space: 6 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
| 2 | Waterbath stunning machine (Larger size) | set | 1 | SUS frame, fiberglass groove | |
| 3 | Air drum type scalding machine (Larger size) | Full closed | set | 1 | Length:3.3m, scalding time:1minute; It includes SUS air drived stirring system, 1 air blower, SUS poultry baffle, SUS shell and steam enclosed cover, SUS rail and corner wheel, water level and temp auto control system; |
| 4 | Vertical defeathering machine | 6 rows with 8 plates each row | set | 1 | Adjustable SUS frame, two parallel cabinets; total 6 rows with 8 plates each row, each plate has 12 rubber whips; 6 belt drive devices, 6 high speed chinlon belts, feather baffle and SUS spray pipe are included; |
| 5 | Hook washing machine (larger size) | set | 1 | SUS frame, 2 nylon brushes and motor drive, 2 SUS brush cabinet and spray pipes | |
| 6 | Automatic poultry unhooking device | set | 1 | Made from SUS | |
| 7 | Carcass chute | set | 1 | Made from SUS | |
| 8 | Electric control cabinet | DK-1 | set | 1 | Used to control the drive equipments in this section |
| II. Evisceration Section | |||||
| 1 | Evisceration hanging conveyor | L=32m | set | 1 | Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
| 2 | Evisceration reception chute | pc | 4 | SUS chute and frame with adjustable legs | |
| 3 | Carcass washing device | pc | 1 | Frame, shell and pipes are made from SUS | |
| 4 | Electric control cabinet | DK-4 | set | 1 | Used to control the drive equipments in this section |
| III. Pre-cooling Section | |||||
| 1 | Spiral pre-cooling Machince(Larger size) | L=9m | set | 1 | Screw diameter:1.8m, including chute, SUS tank and frame, SUS screw propulsion device, auto poultry output system, air-blast system and air blower, motor reducer; Cooling media: cold water or brash ice(cold water chilling unit and slice ice machine) |
| 2 | Carcass reception chute | L=2m L=3m | set | 2 | SUS chute and frame |
| 3 | Electric control cabinet | DK-4 | set | 1 | Used to control the drive equipments in this section |
| Sub-total: | |||||
| IV. Cutting Section | |||||
| 1 | Hanging conveyor for cutting | L=45m | set | 1 | Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
| 2 | Worktable | 1800×900×800 | pc | 15 | SUS frame and adjustable legs, and SUS worktable |
| 3 | Electric control cabinet | DK-3 | set | 1 | Used to control the drive equipments in this section |
| IV. Installation materials cost (Mainly major steel beams, hanging,materials, etc.): Total 15t,buyer can source at your local, we give the drawing or buying from us. | |||||
| V. Installation fees: Including the worker's round tickets, salary $100/day/person, Accommodation. | |||||
| VI. Transportion Cost: To be discussed. | |||||
