Poultry Slaughter Machine and Equipment
USD $550,000 - $650,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Qingdao
You May Like
- Hog Swine Pig Slaughtering Line Carcass Transportation&Store Convey Rail For Slaughterhouse Plant
- Sheep Abattoir Equipment Goat Skin Machine For Lamb Slaughter Line
- Goat Abattoir Carcass Processing Convey Rail For Lamb Slaughtering Machine
- Automatic Cow Slaughterhouse System Hide Puller For Cattle Slaughter Line
- Sheep Equipment Foreleg Conveyor For Goat Slaughter House
- Cow Slaughter Line Collect The Cattle Blood For Cattle Abattoir Machine
Product Details
Condition: | New | Application: | Poultry | Place of Origin: | Shandong, China |
Brand Name: | ONESTOP | Model Number: | N/M | Voltage: | 220V/380V |
Power(W): | 1500W | Dimension(L*W*H): | Chicken Slaughtering Machine | Weight: | 1500kg |
Certification: | ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1000Chickens/h Slaughter and Parting Line
1000 Chickens per hour Slaughter&Cutting Line Equipment List | |||||
No. | Items | Model | Unit | Quantity | Remarks |
I. Slaughter/Scald/Defeather Section | |||||
1 | Hanging conveyor for slaughter | L=88m | set | 1 | Hook space: 6 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
2 | Waterbath stunning machine (Larger size) | set | 1 | SUS frame, fiberglass groove | |
3 | Air drum type scalding machine (Larger size) | Full closed | set | 1 | Length:3.3m, scalding time:1minute; It includes SUS air drived stirring system, 1 air blower, SUS poultry baffle, SUS shell and steam enclosed cover, SUS rail and corner wheel, water level and temp auto control system; |
4 | Vertical defeathering machine | 6 rows with 8 plates each row | set | 1 | Adjustable SUS frame, two parallel cabinets; total 6 rows with 8 plates each row, each plate has 12 rubber whips; 6 belt drive devices, 6 high speed chinlon belts, feather baffle and SUS spray pipe are included; |
5 | Hook washing machine (larger size) | set | 1 | SUS frame, 2 nylon brushes and motor drive, 2 SUS brush cabinet and spray pipes | |
6 | Automatic poultry unhooking device | set | 1 | Made from SUS | |
7 | Carcass chute | set | 1 | Made from SUS | |
8 | Electric control cabinet | DK-1 | set | 1 | Used to control the drive equipments in this section |
II. Evisceration Section | |||||
1 | Evisceration hanging conveyor | L=32m | set | 1 | Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
2 | Evisceration reception chute | pc | 4 | SUS chute and frame with adjustable legs | |
3 | Carcass washing device | pc | 1 | Frame, shell and pipes are made from SUS | |
4 | Electric control cabinet | DK-4 | set | 1 | Used to control the drive equipments in this section |
III. Pre-cooling Section | |||||
1 | Spiral pre-cooling Machince(Larger size) | L=9m | set | 1 | Screw diameter:1.8m, including chute, SUS tank and frame, SUS screw propulsion device, auto poultry output system, air-blast system and air blower, motor reducer; Cooling media: cold water or brash ice(cold water chilling unit and slice ice machine) |
2 | Carcass reception chute | L=2m L=3m | set | 2 | SUS chute and frame |
3 | Electric control cabinet | DK-4 | set | 1 | Used to control the drive equipments in this section |
Sub-total: | |||||
IV. Cutting Section | |||||
1 | Hanging conveyor for cutting | L=45m | set | 1 | Hook space: 8 inches; It consists of T rail, SUS T straight rail, bend rail and connections, SUS drive chain, nylon hanger and SUS plastic trolley, SUS hook, SUS drag chain and drive device and frame. Motor reducer, variable-frequency speed control system, tensioning gear, slewing gear and SUS connections are included. |
2 | Worktable | 1800×900×800 | pc | 15 | SUS frame and adjustable legs, and SUS worktable |
3 | Electric control cabinet | DK-3 | set | 1 | Used to control the drive equipments in this section |
IV. Installation materials cost (Mainly major steel beams, hanging,materials, etc.): Total 15t,buyer can source at your local, we give the drawing or buying from us. | |||||
V. Installation fees: Including the worker's round tickets, salary $100/day/person, Accommodation. | |||||
VI. Transportion Cost: To be discussed. |
