high production concrete block making machine,brick making machine for sale
Introduction of concrete block making machine,brick making machine:
Henan Tong Li brick making machine adopts more advanced hydraulic system at present,not only reduce the noise pollution in the process of production, and the brick produced by this brick machine equipment has higher compactness,in addition,the appearance of the brick is more beautiful. In the raw material,there is no difference with other brick making machine,are stone, sand, furnace slag ,mineral waste residue, cement and so on.The production of this brick machine equipment has more brick type,it truly achieved the goal of multi-usage, and has high cost performance.The production line is the most ideal choice of users that want to investment the brick machine equipment.At the same time it adopts PLC intelligent control, human-machine interface automatic fault diagnosis,the vibration system using electro-hydraulic proportional valve control, achieved the low-frequency charging high frequency vibration molding.In addition,install multi-row the cloth of the stirring fork system, can quickly evenly speak material discharged into molding box, with very flexible.
details of concrete block making machine,brick making machine:
performances and parameters of QYT6-15 concrete block making machine,brick making machine:
1. The equipment adopt the PLC system and controlled by computer, thus can analysis the random signal, diagnose the fault, set the parameter that ensure the production is in safe condition.
2. Storage separate device: the equipment adopt enclosed belt transportation,control the storage of small hopper strictly,thus can achieve the result that once supplied it can be used, preventing the concrete from liquefaction ahead influenced by after shock,make sure the intensity of the product.
3. Reinforced feed device:when the fabric box sent to the above of mould box ,the stirring fork in the fabric box work quickly,ensure the material preparation well-distributed and the intensity of product consistent.
4. Enlarge effective work table-board:This machine have large table-board because of the adoption of new vertical technology,thus greatly improved the production efficiency.
5. Special vibrating form: adopt the flux and the stress of the the hydraulic pressure controlled by computer, it can achieve vertical synchronization vibration,frequency conversion and brake.It change the left oil to vibrating strength,In this way reduce the energy cost.
6. It can produce the fly ash tiles and bricks that consist 80%of the fly ash, do not have to autoclaved ,normal maintain at common atmosphere.
Technical parameters of QYT6-15 concrete block making machine,brick making machine
Moulding Number |
Moulding Cycle |
Capacity |
Power |
Gross Weight |
Overall Dimension |
Brace Dimension |
|
390×190×190 6block/mould 11500block/class
|
About 15second |
About 69120 block /class |
34.5 kw |
9.8T |
6790×2205×2780mm |
850×780× 40mm |
|
240×115×90 18block/mould 34000block/class | ||||||
|
240×115×53 36block/mould 69120block/class
|
Raw materials of QYT6-15 concrete block making machine,brick making machine :
1)Construction garbage
2)Crash stone
3)Sand
4)Slag
5)Cement
6)Fly ash
sample of QYT6-15 concrete block making machine,brick making machine
application of QYT6-15 concrete block making machine,brick making machine
Our service and advantage of concrete block making machine :
1.As 30 years professional concrete block making machine factory with 4 years gold supplier on , we have a lot of manufacturing experience and technique.
2.We provide pre-sale service, middle sale service and after sale service. As your best supplier, we are responsible for teaching you how to operate and maintain the machine,how to produce bricks.
3.We have got some certificates such as ISO9001:2008,CE and BV.
4.We have customers in Malaysia, Taiwan, Switzerland. At the meantime, we also exported our concrete block machine/concrete block making machine / cement block machine to Qatar, Iraq, Egypt, Brazil, India,etc. We have big market in the world.
1.Q: Can this machine make my block?
A: We will design suitable molds according to customers' drawing/picture of blocks.
2.Q: What is your payment term?
A: T/T,L/C, Escrow or others.
3.Q: what is your delivery time?
A: Normally with delivery time within 15 days after deposit.
4.Q: What is your minimum order quantity?
A: one set
5.Q: How about your packing and shipping?
A: Suitable for shipping, usually 20/40 feet container
