F3C Series M12 Inductive Sensors, Cylinder Shape Inductance Sensor, PNP/NPN, Flush/Non-flush
US$ 5 - 10
MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
F&C
Model Number:
F3C/F3L series
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
F3C Series M18 Inductive Proximity Switches DC12-24v Proximity SensorUS$ 5 - 10MOQ: 20 Pieces -
F3C Series M30 Inductive Proximity Sensor, 360 Degrees View LED DC12-24vUS$ 5 - 10MOQ: 20 Pieces
-
FSCU Series M8/M12/M18/M30 Full Metal Body With Protected Tube, Firm Structure, Prevented Collision Damage.US$ 5 - 10MOQ: 20 Pieces
-
FKC Series Liquid Level Sensing, Non-metal Sensing, Cylinder and Square Shape Capacitive Proximity Sensors SwitchesUS$ 20 - 30MOQ: 20 Pieces
-
FKC1810 Series M18 Capacitive Proximity Sensor, With Red Tube Protected From Damage, 3-wire, NPN/PNP, 10mm Sensing Range.US$ 20 - 30MOQ: 20 Pieces
Place of Origin
Hunan, China
Brand Name
F&C
Model Number
F3C/F3L series
Usage
Position Sensor
Theory
Inductance Sensor
Output
Switching Transducer
Product Description
| standard shell/shield | F3C-12KS02-N R2M | NPN.NO | 2mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3C-12KS02-N2 R2M | NPN.NC | ||||
| F3C-12KS02-P R2M | PNP.NO | ||||
| F3C-12KS02-P2 R2M | PNP.NC | ||||
| standard shell/non-shield | F3C-12KN04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3C-12KN04-N2 R2M | NPN.NC | ||||
| F3C-12KN04-P R2M | PNP.NO | ||||
| F3C-12KN04-P2 R2M | PNP.NC | ||||
| short shell/shield | F3C-12ES02-N R2M | NPN.NO | 2mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3C-12ES02-N2 R2M | NPN.NC | ||||
| F3C-12ES02-P R2M | PNP.NO | ||||
| F3C-12ES02-P2 R2M | PNP.NC | ||||
| short shell/non-shield | F3C-12EN04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3C-12EN04-N2 R2M | NPN.NC | ||||
| F3C-12EN04-P R2M | PNP.NO | ||||
| F3C-12EN04-P2 R2M | PNP.NC | ||||
| standard shell/shield/double sensing range | F3L-12KS04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3L-12KS04-N2 R2M | NPN.NC | ||||
| F3L-12KS04-P R2M | PNP.NO | ||||
| F3L-12KS04-P2 R2M | PNP.NC | ||||
| standard shell/non-shield/double sensing range | F3L-12KN08-N R2M | NPN.NO | 8mm | 24×24×1(iron) | φ4×2M/3-wires |
| F3L-12KN08-N2 R2M | NPN.NC | ||||
| F3L-12KN08-P R2M | PNP.NO | ||||
| F3L-12KN08-P2 R2M | PNP.NC | ||||
| short shell/shield/double sensing range | F3L-12ES04-N R2M | NPN.NO | 4mm | 12×12×1(iron) | φ4×2M/3-wires |
| F3L-12ES04-N2 R2M | NPN.NC | ||||
| F3L-12ES04-P R2M | PNP.NO | ||||
| F3L-12ES04-P2 R2M | PNP.NC | ||||
| short shell/non-shield/double sensing range | F3L-12EN08-N R2M | NPN.NO | 8mm | 24×24×1(iron) | φ4×2M/3-wires |
| F3L-12EN08-N2 R2M | NPN.NC | ||||
| F3L-12EN08-P R2M | PNP.NO | ||||
| F3L-12EN08-P2 R2M | PNP.NC |
| Response frequency | 1000Hz/800Hz |
| Hysteresis | 10%≤sensing distance |
| Operating voltage | DC:12~24VDC±10%/ can customize 5V |
| Current consumption | DC:≤8mA No—Load |
| Load current | DC:24V 150mA Max |
| Leakage current | DC:≤0.01mA no-Load |
| Residual votage | DC:≤1.5VDC No-load |
| Operating temperature | -20°C~+70°C |
| Material | PBTand SUS304 |
| Wiring method | 2M/3-wires |
| Protection degree | IP67 |
Diagram
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2013
Factory Size
1,000-3,000 square meters
Total Employees
51 - 100 People
