Specifications
7/16 din rf connector1) straight type
2) cable mount for lmr 540
3) brass,nickel plated
L29 male din rf connector for super flexible rf cable
| Connector type | din male connector | Working Voltage | 335V max |
| Frequency Range | 0-6GHz | vswr | max 1.3 |
| Impedance | 50 Ω | Temp.range | -65~+165°C |
| Conductor resistance | Internal ≤ 1mΩ | Material | Shell:brass, nickel plated |
| External ≤ 0.25mΩ | Nut:brass, nickel plated | ||
| Insulating resistance | ≥ 10000MΩ | pin:brass,gold plating | |
| Withstanding voltage | 4000V rms | Usability | 500 Cycles min |
- Panel connectors
- Terminations
- Adaptors
- Wideband power splitters
- Cable connectors
- Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
- Easy for installation,save time and money
ps:L29 (7/16) series RF coaxial connectors are one of big thread type coaxial connectors researched and developed in accordance with related requirement of IEC 169-4 standard. With the characteristics of stabiity, low loss and high operation voltage and waterproof structure, the product is widely used in microwave transmission and mobile communication systems as medium and high powered outdoor connectors.
our main market: north America South America Eastern Europe
Southeast Asia Africa Oceania
Mid East Eastern Asia Western Europe
Central America Southern Europe South Asia
PS:
- OEM are welcome
- high quality but low price
- We have many types connector for your choosing, if you have any query please fell free to contact me, I am glad service for you
- We have professional team to service for you, please tell me your detail information then I will offer you the right products you need
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
