Sma Jack Female RF Cable Connectors Pcb
US$ 0.15 - 2
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DB Connector
Model Number:
DB-011
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
50ohm SMA Type ConnectorUS$ 0.1 - 0.9MOQ: 1000 Pieces -
Hot Sale 90 Degree Coaxia Cable Rg6 With Sma Connector Db002 From Dongber FactoryUS$ 0.1 - 1.5MOQ: 1000 Pieces
-
Smb rf Coaxial Connector for Rg58 Rg8 Rg174 Rg316US$ 0.1 - 1MOQ: 1000 Pieces
-
RP SMA Solder Jack Flange Coaxial Cable Circular Connector AdapterUS$ 0.15 - 2MOQ: 1000 Pieces
-
rf Coaxial Cable Sma Switch ConnectorUS$ 0.1 - 1MOQ: 1000 Pieces
Place of Origin
Jiangsu, China
Brand Name
DB Connector
Model Number
DB-011
Type
SMA
Application
RF
Gender
Female
Specifications
SMA cable connector pcb1.small-sized thread coupling
2.wide frequency range
3.excellent performance
4.ISO9001 pass,OEM/ODM
sma jack female RF cable connectors pcb
| Mechanical Characteristics | |
| Characteristic Impedance: | 50Ω |
| Frequency Range: | Flexible: 0-11GHz |
| Semi-rigid cable: 0-18GHz | |
| Withstand Voltage: | ≥2500V,50Hz |
| Working Voltage: | ≤1000V,50Hz (see level) |
| Insulation Resistance: | ≥5000mΩ |
| Contact Resistance: | Inner conductor: ≤1.0mΩ |
| Outer conductor: ≤0.2mΩ | |
| RF leakage(2-3GHZ): | Flexible: ≥90dB |
| 3rd order intermodulation | ≥140dBc |
| Material | |
| Pin conductor: | Brass--Au plated |
| Shell: | Brass--Ternary Alloy (Cu+Zn+Sn) plated |
| Socket: | Phosphor bronze / Beryllium copper--Au/Ag plated |
| Crimping suite: | Copper--Ternary Alloy (Cu+Zn+Sn) |
| Insulator: | PTFE / PFA |
| Sealing: | Silastic |
Applications:
- GSM SystemGPS Navigation System Wireless Communication System
- Antennas
- Car Radio
- Test Equipment
- Microwave Components
- Data Transmission
- Lan System
- Satellite Transmission
- Aviation Equipmen
Dongbei QC Team
- Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
- We highly appreciate your any enquiry by email, fax or instant message.
- We will reply your email or fax within 12 hours.
- Please fell free to call us at any time if there is any questions.
Transportation
- All available shipping ways could be applied, by courier, air or sea.
- Appointed shipping company or our own forwarders all could be used in shipment.
- Full-way tracking the cargos for you before the goods arrive.
How to place order?
- send you inquiry to get catalog.
- choose the models you would like to buy.
- confirm the total quantity&freight.
- Do the payment.
