64KW 3-phase toroidal transformer MPPT solar system hybrid inverter 380v wire to wire
GENERAL DESCRIPTION:
These series of inverters are hybrid inverter with built-in MPPT solar charge controller. Advantages include high conversion efficiency, low power consumption, strong loading ability etc.. Users can set battery charging mode, timing DC/AC mode to meet different requirements.This is the most high-end low frequency inverter with built-in MPPT solar charge controller.
PRODUCT FEATURES
_________________________________________________________________________________
- Intelligent design, simple structure, powerful control functions, stable performance, safe and reliable.
- Transfer efficiency up to 99%, saving 30%~60% solar panels compared with traditional controllers.
- With efficient MPPT operation scheme, the utilization rate of solar panels reaches 99%
- Intelligent design, lifelong service of on-line upgrade.
- All components are of famous brands, able to resist high temperature over 105℃, theoretically with design life of 10 years.
- Wide input working voltage range of solar panels.
- LCD display of various parameters, such as model, PV input voltage, type of battery, battery voltage, charging current, charging power, and charging status, etc.
- Reverse charging avoidable with solar energy, when the light is weak, e.g. in the night, the voltage of the battery may be higher than the terminal voltage of the solar arrays, but this controller is designed with the anti-reverse charging circuit to prevent the battery from reversely charging the solar cell.
- The battery and the equipment can be effectively protected due to the broken circuit caused by the fuse in the controller circuit, although reverse connection occurs, which is equal to short circuit and can result in a large instantaneous current.
- Automatic cutting off the circuit by the overload protection controller
PRAMETERS:
| MODEL: SC-GT | 6/10KVA | 15/20/30KVA | 40/50/60KVA | 80/100/120KVA |
| Phase System | 3-phase 3-wire system | |||
| Power Factor | 0.8 PF | |||
| Display | Full-function graphical LCD display | |||
| PV INPUT | ||||
| Max Input Voltage | 280Vdc | 420Vdc | 674Vdc | |
| Max Input Current | 33A/55A | 41A/55A/83A | 55A/69A/83A | 110A/138A/166A |
| AC POWER INPUT | ||||
| Input Connections | 3-phase 4-wire + Safety Grounding Wire | |||
| Input Voltage Range | 260~460Vac | |||
| Input Frequency Range | 45Hz~65Hz | |||
| Charging Current | 0-50A | |||
| SOLAR CHARGING CONTROLLER | ||||
| Type | MPPT | |||
| Input Voltage Range | 110~220Vdc | 220~360Vdc | 440~680Vdc | |
| Max Charging Current | 100A | 150A | 300A | |
| Protection | High/Low Voltage; Overload; Over-temperature; Short-circuit; Anti-reverse | |||
| OUTPUT | ||||
| Voltage | 380V ± 5%(battery mode); 380V ± 15%(utility mode) | |||
| Current | 300A max | |||
| Frequency | 50/60Hz ± 0.5% | |||
| Efficiency | >99%(Utility mode); >80%(Invertion mode) | |||
| Transfer Time | ≤1.5ms | |||
| Wave Distortion | When the load varies from 0 to 100%, the voltage variation <3% | |||
| Distortion Degree | Pure sine wave, harmonic wave distortion <3% (linear load) | |||
| THD | <3% (linear load); <10%(non-linear load) | |||
| BATTERY | ||||
| Type | Maintenance free lead-acid battery | |||
| Voltage | 96Vdc(12Vdc*8pcs) | 192Vdc(12Vdc*16pcs) | 384Vdc(12Vdc*32pcs) | |
| Balanced Charging Voltage | 112~113.6Vdc | 224~227.2Vdc | 448~454.4Vdc | |
| Float Charging Voltage | 110Vdc | 220Vdc | 440Vdc | |
| PROTECTION | ||||
| Overload Protection | Battery mode: ≥110%, 30S; ≥120%, 2S. Utility mode: won't switch off, but buzz to alarm. | |||
| Short-circuit Protection | Alarm in 20s, then closing the inverter | |||
| High/Low Input Voltage Protection |
Available | |||
| Battery Reverse Polarity Protection |
Available | |||
| High-temperature Protection | Available | |||
| SYSTEM & ENVIRONMENT | ||||
| Efficiency | >99% | |||
| Communication Interface | RS232/RS485(optional) | |||
| Heat-dissipating method | Cooling fan | |||
| Noise | <45db(lm) | |||
| Working temperature | 0~40℃ | |||
| Working humidity | 20%~90% (non-condensing) | |||
| Protection grade | IP20 | |||
| SPECIFICATIONS | ||||
| DimensionWxHxD(mm) | 595*286*765 | 710*386*865 | 700*445*1110 | 1000*600*1350 |
| Weight(kgs) | 60-70 | 90-130 | 250-300 | 500-550 |
| COMMUNICATION FUNCTION | ||||
| Smart RS-232/USB | Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and MAC | |||
| SNMP Optional | Power management from SNMP supervisor and web browser | |||
|
* SCPOWER is dedicated to technology innovation and always attemps to deliver to customers the best products and services, therefore, all specifications subject to change, please consider real sample as final. * THD = Total Harmonic Distortion | ||||
PRODUCT PHOTOS
___________________________________________________________________________________________________
Machine Performance Testing:
Series of testings are arranged by professional engineers before packed and shipped.
Standard Packing:
Transparent plastic bag sealed;
EPE corner protection;
Carton box packed+packing strings / wood box
(Customized Packing is also available.)
Shipping Method:
Air shipping, sea shipping or train shipping is either accepable;
We promise to arrange shipping in lowest cost for customer.
- Strict Quality Control Service:we promise inspect every machine before packing
- Software upgrade service
- Free provides of spare parts within warranty
- Online/Onsite training of installation, debugging, maintenance, reparation etc.
- Consolidation Service( only peripherals of our products)
- Promotion Support
- After sale services
Q1:Did your inverter include charger?
A1:Yes.
Q2: What's the different between power inverter and hybrid inverter?
A2: Hybrid built-in MPPT solar charge controller,but power inverter not.
Q3:Do you have MOQ request?
A3:We always accept trial order.At the moment we don't have MOQ request.
Q4:What payment terms do you offer?
A4:T/T,western union,LC,Cash.
Q5: How about the delivery time?
A5: As usual 10-16 working days for sample; mass order depends on quantity.
Q6: What is the product warranty?
A6: One year .
Q7:Can you help on arrange the shipment?
A7:Yes,please offer your nearest destination port name to our custom service assistant.
Q8:I need OEM product?
A8:it's welcome.please show us your idea.
