3 phase Solar Inverter dc to ac 6-10kva with built-in MPPT controllerr
|
*Intelligent design, simple structure, powerful control functions, stable performance, safe and reliable. *Transfer efficiency up to 99%, saving 30%~60% solar panels compared with traditional controllers. *With efficient MPPT operation scheme, the utilization rate of solar panels reaches 99% *Intelligent design, lifelong service of on-line upgrade. *All components are of famous brands, able to resist high temperature over 105℃, theoretically with design life of 10 years. *Wide input working voltage range of solar panels. *Reverse charging avoidable with solar energy, when the light is weak, *The battery and the equipment can be effectively protected due to the broken circuit caused by the fuse in the controller circuit, although reverse connection occurs, which is equal to short circuit and can result in a large instantaneous current. *Automatic cutting off the circuit by the overload protection controller,
|
|
PARAMETERS:
| MODEL | SC-GT 6/10KVA | SC-GT 15/20/30KVA |
| Phase System | 3-phase 3-wire system | |
| Power Factor | 0.8 PF | |
| Display | Full-function graphical LCD display | |
| PV Input | ||
| Max Input Voltage | 280Vdc | 420Vdc |
| Max Input Current | 33A/55A | 41A/55A/83A |
| AC Power Input | ||
| Input Connections | 3-phase 4-wire + Safety Grounding Wire | |
| Input Voltage Range | 260~460Vac | |
| Input Frequency Range | 45Hz~65Hz | |
| Charging Current | 0-50A | |
| Solar Charging Controller | ||
| Type | MPPT | |
| Input Voltage Range | 110~220Vdc | 220~360Vdc |
| Max Charging Current | 100A | 150A |
| Protection |
High/Low Voltage; Overload; Over-temperature; Short-circuit; Anti-reverse |
|
| Output | ||
| Voltage | 380V ± 5%(battery mode); 380V ± 15%(utility mode) | |
| Current | 300A max | |
| Frequency | 50/60Hz ± 0.5% | |
| Efficiency | >99%(Utility mode); >80%(Invertion mode) | |
| Transfer Time | ≤1.5ms | |
| Wave Distortion | When the load varies from 0 to 100%, the voltage variation <3% | |
| Distortion Degree | Pure sine wave, harmonic wave distortion <3% (linear load) | |
| THD | <3% (linear load); <10%(non-linear load) | |
| Battery | ||
| Type | Maintenance free lead-acid battery | |
| Voltage | 96Vdc(12Vdc*8pcs) | 192Vdc(12Vdc*16pcs) |
| Balanced Charging Voltage | 112~113.6Vdc | 224~227.2Vdc |
| Float Charging Voltage | 110Vdc | 220Vdc |
| Protection | ||
| Overload Protection |
Battery mode: ≥110%, 30S; ≥120%, 2S. Utility mode: won't switch off, but buzz to alarm. |
|
| Short-circuit Protection | Alarm in 20s, then closing the inverter | |
|
High/Low Input Voltage Protection |
Available | |
|
Battery Reverse Polarity Protection |
Available | |
|
High-temperature Protection |
Available | |
| System and Environment | ||
| Efficiency | >99% | |
| Communication Interface | RS232/RS485(optional) | |
| Heat-dissipating method | Cooling fan | |
| Noise | <45db(lm) | |
| Working temperature | 0~40℃ | |
| Working humidity | 20%~90% (non-condensing) | |
| Protection grade | IP20 | |
| Specifications | ||
| DimensionWxHxD(mm) | 595*286*765 | 710*386*865 |
| Weight(kgs) | 60-70 | 90-130 |
| Communication Function | ||
| Smart RS-232/USB |
Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and MAC |
|
| SNMP Optional | Power management from SNMP supervisor and web browser | |
|
SCPOWER is dedicated to technology innovation and always attemps to deliver to customers the best products and services, therefore, all specifications subject to change, please consider real sample as final. THD = Total Harmonic Distortion | ||
