SC-VT 100KVA Industrial Uses Three Phases Inverter
FEATURES:
Intelligent design, simple structure, powerful control functions, stable performance, safe and reliable.
Intelligent design, lifelong service of on-line upgrade.
All components are of famous brands, able to resist high temperature over 105℃, theoretically with design life of 10 years.
Reverse charging avoidable with solar energy, when the light is weak, e.g. in the night, the voltage of the battery may be higher than the terminal voltage of the solar arrays, but this controller is designed with the anti-reverse charging circuit to prevent the battery from reversely charging the solar cell.
The battery and the equipment can be effectively protected due to the broken circuit caused by the fuse in the controller circuit, although reverse connection occurs, which is equal to short circuit and can result in a large instantaneous current.
Automatic cutting off the circuit by the overload protection controller
PARAMETERS:
| MODEL | SC-VT 40/50/60KVA | SC-VT 80/100/120KVA |
| Phase System | 3-phase 3-wire system | |
| Power Factor | 0.8 PF | |
| Display | Full-function graphical LCD display | |
| AC Power Input | ||
| Input Connections | 3-phase 4-wire + Safety Grounding Wire | |
| Input Voltage Range | 260~460Vac | |
| Input Frequency Range | 45Hz~65Hz | |
| Charging Current | 0-50A | |
| Output | ||
| Voltage | 380V ± 5%(battery mode); 380V ± 15%(utility mode) | |
| Current | 300A max | |
| Frequency | 50/60Hz ± 0.5% | |
| Efficiency | >99%(Utility mode); >80%(Invertion mode) | |
| Transfer Time | ≤1.5ms | |
| Wave Distortion | When the load varies from 0 to 100%, the voltage variation <3% | |
| Distortion Degree | Pure sine wave, harmonic wave distortion <3% (linear load) | |
| THD | <3% (linear load); <10%(non-linear load) | |
| Battery | ||
| Type | Maintenance free lead-acid battery | |
| Voltage | 384Vdc(12Vdc*32pcs) | |
| Balanced Charging Voltage | 448~454.4Vdc | |
| Float Charging Voltage | 440Vdc | |
| Protection | ||
| Overload Protection | Battery mode: ≥110%, 30S; ≥120%, 2S. Utility mode: won't switch off, but buzz to alarm. |
|
| Short-circuit Protection | Alarm in 20s, then closing the inverter | |
| High/Low Input Voltage Protection |
Available | |
| Battery Reverse Polarity Protection |
Available | |
| High-temperature Protection | Available | |
| System and Environment | ||
| Communication Interface | RS232/RS485(optional) | |
| Heat-dissipating method | Cooling fan | |
| Noise | <45db(lm) | |
| Working temperature | 0~40℃ | |
| Working humidity | 20%~90% (non-condensing) | |
| Protection grade | IP20 | |
| Specifications | ||
| DimensionWxHxD(mm) | 700*445*1110 | 1000*600*1350 |
| Weight(kgs) | 250-300 | 500-550 |
| Communication Function | ||
| Smart RS-232/USB | Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and MAC |
|
| SNMP Optional | Power management from SNMP supervisor and web browser | |
|
*SCPOWER is dedicated to technology innovation and always attemps to deliver to customers the best products and services, therefore, all specifications subject to change, please consider real sample as final. *THD = Total Harmonic Distortion | ||
