SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase

SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-1
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-2
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-3
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-4
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-5
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase thumbnail-6
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-1
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-2
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-3
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-4
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-5
SC-GT 3KVA 3 Phase Transformer Step Down Transformer 380v to 220v 3 Phase photo-6
US$ 1,000 - 1,500 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SCPOWER
Model Number:
SC-GT 3KVA
Contact Supplier Request Quote Chat Now
Foshan SC Power Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOSHAN SHENZHEN GUANGZHOU HONGKONG
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SCPOWER
Model Number SC-GT 3KVA
Specification Normal
Application Industrial
Output Voltage (V) 380V-415V
Load Power (W) 2400w
Solar Power (W) 3000w
Work Time (h) 24 Hours

SC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phase



GENERAL DESCRIPTION:

     These series of inverters are hybrid inverter with built-in MPPT solar charge controller. Advantages include high conversion efficiency, low power consumption, strong loading ability etc.. Users can set battery charging mode, timing DC/AC mode to meet different requirements.This is the most high-end low frequency inverter with built-in MPPT solar charge controller.





PRODUCT FEATURES

_____________________________________________________________________________



  • Intelligent design, simple structure, powerful control functions, stable performance, safe and reliable.
  • Transfer efficiency up to 99%, saving 30%~60% solar panels compared with traditional controllers.
  • With efficient MPPT operation scheme, the utilization rate of solar panels reaches 99%
  • Intelligent design, lifelong service of on-line upgrade.
  • All components are of famous brands, able to resist high temperature over 105℃, theoretically with design life of 10 years.
  • Wide input working voltage range of solar panels.
  • LCD display of various parameters, such as model, PV input voltage, type of battery, battery voltage, charging current, charging power, and charging status, etc.
  • Reverse charging avoidable with solar energy, when the light is weak, e.g. in the night, the voltage of the battery may be higher than the terminal voltage of the solar arrays, but this controller is designed with the anti-reverse charging circuit to prevent the battery from reversely charging the solar cell.
  • The battery and the equipment can be effectively protected due to the broken circuit caused by the fuse in the controller circuit, although reverse connection occurs, which is equal to short circuit and can result in a large instantaneous current.
  • Automatic cutting off the circuit by the overload protection controller





PRAMETERS:



MODEL: SC-GT 6/10KVA 15/20/30KVA 40/50/60KVA 80/100/120KVA
Phase System 3-phase 3-wire system
Power Factor 0.8 PF
Display Full-function graphical LCD display
PV INPUT
Max Input Voltage 280Vdc 420Vdc 674Vdc
Max Input Current 33A/55A 41A/55A/83A 55A/69A/83A 110A/138A/166A
AC POWER INPUT
Input Connections 3-phase 4-wire + Safety Grounding Wire
Input Voltage Range 260~460Vac
Input Frequency Range 45Hz~65Hz
Charging Current 0-50A
SOLAR CHARGING CONTROLLER
Type MPPT
Input Voltage Range 110~220Vdc 220~360Vdc 440~680Vdc
Max Charging Current 100A 150A 300A
Protection High/Low Voltage; Overload; Over-temperature; Short-circuit; Anti-reverse
OUTPUT
Voltage 380V ± 5%(battery mode); 380V ± 15%(utility mode)
Current 300A max
Frequency 50/60Hz ± 0.5%
Efficiency >99%(Utility mode); >80%(Invertion mode)
Transfer Time ≤1.5ms
Wave Distortion When the load varies from 0 to 100%, the voltage variation <3%
Distortion Degree Pure sine wave, harmonic wave distortion <3% (linear load)
THD <3% (linear load); <10%(non-linear load)
BATTERY
Type Maintenance free lead-acid battery
Voltage 96Vdc(12Vdc*8pcs) 192Vdc(12Vdc*16pcs) 384Vdc(12Vdc*32pcs)
Balanced Charging Voltage 112~113.6Vdc 224~227.2Vdc 448~454.4Vdc
Float Charging Voltage 110Vdc 220Vdc 440Vdc
PROTECTION
Overload Protection Battery mode: ≥110%, 30S; ≥120%, 2S. Utility mode: won't switch off, but buzz to alarm.
Short-circuit Protection Alarm in 20s, then closing the inverter
High/Low Input
Voltage Protection		 Available
Battery Reverse
Polarity Protection		 Available
High-temperature Protection Available
SYSTEM & ENVIRONMENT
Efficiency >99%
Communication Interface RS232/RS485(optional)
Heat-dissipating method Cooling fan
Noise <45db(lm)
Working temperature 0~40℃
Working humidity 20%~90% (non-condensing)
Protection grade IP20
SPECIFICATIONS
DimensionWxHxD(mm) 595*286*765 710*386*865 700*445*1110 1000*600*1350
Weight(kgs) 60-70 90-130 250-300 500-550
COMMUNICATION FUNCTION
Smart RS-232/USB Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix and MAC
SNMP Optional Power management from SNMP supervisor and web browser

* SCPOWER is dedicated to technology innovation and always attemps to deliver to customers the best products and services, therefore, all specifications subject to change, please consider real sample as final.

* THD = Total Harmonic Distortion











PRODUCT PHOTOS

_________________________________________________________________________________________________

SC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phaseSC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phaseSC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phase

Company Information

  Founded in 2009, Foshan SC Power Technology Ltd. is a National Key Support High-Tech Enterprise which integrated with R&D, production and marketing of Solar Inverter, Solar MPPT Controller, Hybrid Inverter (inverter with controller) and related solar power system products.



  OUR ADVANTAGES:

  • Rapid growing industry

  • We are factory

  • High spirit team

  • Master core technology

  • Fast response and quality service

  • Full set of self-developing tools convenient to modify custom settings

  • Full team support for sales and technical services

  PRODUCTION ABILITY:

  • 5000sets/month ( Inverter/Hybrid Inverter)

  • 10000sets/month (MPPT Solar Charge Controller)

  R & D:

  • OEM / ODM acceptable

Warmly welcome to inquiry & place orders and wish we have a win-win business cooperation.



SC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phase



FACTORY BUILDING & OFFICE BUILDING

SC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phase



FACTORY & OFFICE INNER VIEW

















Order & Contact





Please Provide Below Info Before Placing an Order

  • Step 1:

Utility Voltage & Frequency, example:

   * China, Germany, Poland:      220Vac 50Hz

   * USA, Venezuela, Panama:    120/240Vac 60Hz


  • Step 2:

Battery Voltage: Please refer to our datasheet above.

  • Step 3:

Please choose mountain style, display type and pattern:

SC-GT 3KVA 3 phase transformer step down transformer 380v to 220v 3 phase

  • Step 4:

Loads Type, please tell us most part of loads type you are going to apply:

   * Resistive Load: filament lamp, electric water heater/oven/cooker/teakettle/radiator, etc.

   * Capacitive Load: computer, TV, game machine, LED light, energy saving lamp, etc.

   * Inductive Load: aircon, washer, refrigerator, fan, transformer, induction cooker, microwave oven, etc.

  • Step 5:

Trade information:

   * Company & Contact information

   * Quantity

   * Payment method

  • Step 6:

Working Environment: Please provide

Warranty Extending:  Please choose from 1~5 years

  • Step 7:

Other special requirements:  such as preferable shipment method, OEM, retail packaging, etc.
