Specifications
Solar tracking system 10kw:1.Competitive price
2.Professional and concise design
3.High quality
4.Quick delivery
Solar tracking system 10kw
This Solar tracking system 10kw is designed based on mechanics and is made of high-quality aluminum and hot dip galvanized steel, so it can have 25-year service life. Besides, we promise with 10 years of warranty. The generating efficiency will be improved by 30%-40%. Because when the sun is changing, the tracker is also changing accordingly, the absorption of the solar radiation will be improved. Besides, because of the emergency device, if the wind is larger than the wind resistance of the Solar tracking system 10kw , it can adjust the angle to horizontal automatically in order to decrease the wind load. Finally, our engineer will calculate the suitable panel capacity for you according to your panel dimension.
Solar tracking system 10kw
Technical data:
Azimuth control | Drive | Worm drive(Roller bearing) | |
Control Angle (Horizontal) | 270° | ||
Motor | 2,800PRM(120W/DC240V) | ||
Elevation | Drive | Liner actuator | |
Control Angle (Vertical) |
-45 °to +45 ° | ||
Motor | 2,800RPM(120W/DC240V)/(Ration288:1→10.4RPM) | ||
Max. Power consumption | 160W | ||
Main Materials | Galvanized steel | ||
Tracking method | Standard: Solar-Sensor tracking/Optional: Data-tracking | ||
Controller | Auto mode/Manual mode | ||
Tracking accuracy tolerance | ±0.1° | ||
Min. sunlight for tracking | 300W/m² | ||
Foundation |
| ||
Max. Wind load | Normal operation | 14m/s(50km/h) | |
Safety mode(0°) | 35m/s(126km/h) | ||
At45°angle(Constant) | 25m/s(90km/h) | ||
At 45°angle(Instant) | 66.5m/s(230km/h) | ||
Night mode(Horizontal idling mode | 1)Below300W/m²over2hours. 2)Warnings from sensors | ||
Generating efficiency improved | 30% - 40% | ||
Warranty | Mechanical parts:10years Electrical parts: 1 year | ||
Solar tracking system 10kw ——CY-ZJ12
1. Install the panels:
2. Lifting the solar table:
3. Panoramagram:
Why choose our CY Solar tracking system 10kw?
1. Easy installation.
The professional and concise design makes this Solar tracking system 10kw install very easily. Some of the components have been pre-assembled at our factory. So it not only saves your installation time but labor. Your schedule will be shortened and budget will also be decreased accordingly.
2. High quality.
This Solar tracking system 10kw has the certificates of RoSH, CE and ISO9001 with 25-year service life. Also we provide the 10 year of warranty.
3. Competitive price.
As we are a manufacturer, our price is very competitive in this market.
4. Design.
We have a professional engineering team who can provide you with the most economical and suitable design for your project according to your requirements.
5. Quick delivery
The safety package and quick delivery.
