SC-MH 192V 20A solar charge controller 100a solar tracker controller
- 10000 Piece / Pieces per Month
- FOSHAN SHENZHEN GUANGZHOU HONGKONG
- T/T Credit Card
You May Like
-
SC-MH 40A Manufacturer mppt charge controller for home energy solar
-
SC-MH 192V 50A mppt solar charge controller kit energia solar
-
SC-MH 192V 60A power bank mobile battery charger circuit diagram
-
SC-MH 240V 25A solar power system home air conditioner price
-
SC-MH 240V 30A solar system home price solar water pump for agriculture
-
SC-MH 240V 40A solar tracker solar system information in hindi
Product Details
| Place of Origin | Guangdong, China | Brand Name | SCPOWER | |
| Model Number | SC-MH 192V 20A | Application | Charger Controller | |
| Rated Voltage | Other, 192V | Maximum Current | 20A |
Product Description
SC-MH 192V 20A solar charge controller 100a solar tracker controller
GENERAL DESCRIPTION:
SC-MH DC192V high-end series ranked the first among MPPT solar charge controllers. Advantages include high conversion efficiency, system automatic recognition, wide range of PV input, professional PC monitoring software etc.. This is the most classical version of MPPT solar charge controller.
PRODUCT FEATURES
____________________________________________________________________________________________
| Max PV Input DC 430V |
| SCP MPPT SOLAR CHAGE CONTROLLER |
| Peak Efficiency Up to 99% |
| Maximum power point track |
| Charging Method MPPT |
| Software Online-Upgrade |
| CE Approved PV CHARGER |
| Unlimited PARALLEL |
BATTERY OPTIONS
_____________________________________________________________________________________________
+ | + | + | + | |||||
Sealed Lead | GEL Battery | Vented Battery | Ni-Cd Battery | |||||
- | - | - | - |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS
_____________________________________________________________________________________________
SC-MH MPPT Solar Charge Controller DC192V High-End Series | |||||||
SC-MH (DC192V) | 20A | 25A | 30A | 40A | 50A | 60A | |
Charge Mode | MPPT (maximum power point tracking) | ||||||
Charge Method | 3 stages: constant current, constant voltage, floating charge | ||||||
MPPT Efficiency | 96V System | ≥96.5%,≤99% | |||||
INPUT CHARACTERISTICS | |||||||
MPPT working voltage range | 192V System | DC220V~DC360V | |||||
Max. PV Voltage | 192V System | DC430V | |||||
Max. PV Power | 192V System | 4400W | 5500W | 6600W | 8800W | 11000W | 13200W |
CHARGE CHARACTERISTICS | |||||||
Battery Type (Default Gel Battery) | 192V System | Sealed lead acid, Vented, Gel, NiCd battery | |||||
Rated Input Current | 192V System | 20A | 25A | 30A | 40A | 50A | 60A |
MECHANICAL CHARACTERISTICS | |||||||
Size D x W x H(mm) | 155*308*86 | ||||||
N.W.(kgs) | 4 | ||||||
G.W.(kgs) | 4.5 | ||||||
The specification is only for reference, subject to change without without prior notice! | |||||||
PRODUCT PHOTOS
