SC-MH 120V 30A solar electricity generating system for home
GENERAL DESCRIPTION:
SC-MH DC120V high-end series ranked the first among MPPT solar charge controllers. Advantages include high conversion efficiency, system automatic recognition, wide range of PV input, professional PC monitoring software etc.. This is the most classical version of MPPT solar charge controller.
PRODUCT FEATURES
____________________________________________________________________________________________
| Max PV Input DC 300V |
| SCP MPPT SOLAR CHAGE CONTROLLER |
| Peak Efficiency Up to 99% |
| Maximum power point track |
| Charging Method MPPT |
| 96V 30A SOLAR CHARGER |
| Software Online-Upgrade |
| CE Approved PV CHARGER |
| Unlimited PARALLEL |
BATTERY OPTIONS
_____________________________________________________________________________________________
+ | + | + | + | |||||
Sealed Lead | GEL Battery | Vented Battery | Ni-Cd Battery | |||||
- | - | - | - |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS
_____________________________________________________________________________________________
SC-MH MPPT Solar Charge Controller DC120V High-End Series | |||||||
SC-MH (DC120V) | 20A | 25A | 30A | 40A | 50A | 60A | |
Charge Mode | MPPT (maximum power point tracking) | ||||||
Charge Method | 3 stages: constant current, constant voltage, floating charge | ||||||
MPPT Efficiency | 96V System | ≥96.5%,≤99% | |||||
INPUT CHARACTERISTICS | |||||||
MPPT working voltage range | 120V System | DC140V~DC260V | |||||
Max. PV Voltage | 120V System | DC300V | |||||
Max. PV Power | 120V System | 2760W | 3450W | 4140W | 5520W | 6900W | 8280W |
CHARGE CHARACTERISTICS | |||||||
Battery Type (Default Gel Battery) | 120V System | Sealed lead acid, Vented, Gel, NiCd battery | |||||
Rated Input Current | 120V System | 20A | 25A | 30A | 40A | 50A | 60A |
MECHANICAL CHARACTERISTICS | |||||||
Size D x W x H(mm) | 155*308*86 | ||||||
N.W.(kgs) | 4 | ||||||
G.W.(kgs) | 4.5 | ||||||
The specification is only for reference, subject to change without without prior notice! | |||||||
PRODUCT PHOTOS
___________________________________________________________________________________________________
