solar charge controllers with rs232 30A controller in chnia SC-MC30A
__________________________________________________________________________________________________
GENERAL DESCRIPTION:
SC-MC series is the smart MPPT solar charge controller that is one of the important parts in the off-grid solar system. Advantages include high conversion efficiency, system automatic recognition, wide range of PV input, professional PC monitoring software etc..This is the most classical version of MPPT solar charge controller
BATTERY OPTIONS
_____________________________________________________________________________________________
+ | + | + | + | |||||
Sealed Lead | GEL Battery | Vented Battery | Ni-Cd Battery | |||||
- | - | - | - |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS
_____________________________________________________________________________________________
SC-MC STANDARD SERIES SOLAR CHARGE CONTROLLER | |||||||
SC-MC Series | 20A | 25A | 30A | 40A | 50A | 60A | |
Charge Mode | MPPT (maximum power point tracking) | ||||||
Charge Method | 3 stages: constant current, constant voltage, floating charge | ||||||
MPPT Efficiency | 12/24/48V | ≥99% | |||||
INPUT CHARACTERISTICS | |||||||
MPPT working voltage range | 12V System | DC18V~DC72V | |||||
24V System | DC34V~DC72V | ||||||
48V System | DC65V~DC144V | ||||||
Low input voltage protection point | 12V System | DC16V | |||||
24V System | DC30V | ||||||
48V System | DC60V | ||||||
Low input voltage recovery point | 12V System | DC22V | |||||
24V System | DC34V | ||||||
48V System | DC65V | ||||||
High input voltage protection point | 12/24/48V System | DC90V/DC90V/DC180V | |||||
High input voltage recovery point | 12/24/48V System | DC85V/DC85V/DC170V | |||||
Maximum PV Power | 12V System (W) | 290W | 350W | 460W | 570W | 700W | 900W |
24V System (W) | 570W | 700W | 900W | 1130W | 1400W | 1700W | |
48V System (W) | 1130W | 1400W | 1700W | 2270W | 2800W | 3400W | |
CHARGE CHARACTERISTICS | |||||||
Battery Type (Default Gel Battery) | 12/24/48V System | Sealed lead acid, Vented, Gel, NiCd battery (Other types of the batteries optional) | |||||
Rated Input Current | 12/24/48V System | 20A | 25A | 30A | 40A | 50A | 60A |
MECHANICAL CHARACTERISTICS | |||||||
Size D x W x H(mm) | 276*241*100 | ||||||
N.W.(kgs) | 3 | 3 | 3 | 3 | 3 | 3.5 | |
G.W.(kgs) | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 | 4 | |
The specification is only for reference, subject to change without without prior notice! | |||||||
PRODUCT PHOTOS
___________________________________________________________________________________________________
SHIPPMENT OPTIONS:
Multiple options for shipment: Express; Air Cargo; Sea Freight; Door to Door by sea freight for some locations, etc.
