BMS, PCB, 36V 12S Battery Management System

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Application:

Lifepo4 battery,LiNCM Battery

Shenzhen Benergy Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Application Lifepo4 battery,LiNCM Battery

Specifications

12S Li-NCM/ Lifepo4/LiMnO/Li-CoO battery pack BMS.
Complete over-charge, over-discharge,over-current, short-circuit protection.

12S BMS for Li-NCM/ Lifepo4/LiMnO/Li-CoO battery pack.

Can bear 160A continuous dischare current.

1. Application and characteristic:

a. Suitable for 12 series Li-NCM/ Lifepo4/LiMnO/Li-CoO battery pack.

b. Complete over-charge, over-discharge,over-current, short-circuit protection function.

C. With balancing function.

2. Parameter

No	Testing content	Minimum	Typical	Maximum	Unit
1	Charging voltage	43.6	43.8	44.0	V
2	Charging current		160	160	A
3	Discharging current		160	160	A
4	Over-current protection (100A load)	630	680	730	A
5	Single cell self-consuming flow(3.65V)	90	110	130	uA
6	Single cell balancing voltage	3.65	3.68	3.70	V
7	Single cell balancing current	190	210	230	mA
8	Single cell over-charge testing voltage	3.80	3.90	4.0	V
9	Single cell over discharge recover voltage	3.70	3.80	3.90	V
10	Over discharge testing delay	96	120	144	ms
11	Single cell over-discharge testing voltage	1.90	2.00	2.10	V
12	Over-discharge recover voltage	2.20	2.30	2.40	V
13	Over-discharge recover testing delay	115	144	172	mS
14	Short circuit/ over discharge/ over current protection recover (100A load)	Would recover automatically after remove the load if any short-circuit/over-discharge/over-current
15	Protection wire IR		0.4	0.6	mΩ
16	Normal current Mosfet temperature raising (max load)		35	60	ºC
17	Battery Discharge temperature protection	60	65	70	ºC
18	Working temperature	-20	25	45	ºC
19	Storage temperature	20	25	30	ºC
