500W Charger, Lithium Battery Charger, Lifepo4 Battery Charger 24V 15A

Name: 500W Charger, Lithium Battery Charger, Lifepo4 Battery Charger 24V 15A
Brand: Benergy
SKU: 124504207
Availability: InStock

500W Charger, Lithium Battery Charger, Lifepo4 Battery Charger 24V 15A thumbnail-1

500W Charger, Lithium Battery Charger, Lifepo4 Battery Charger 24V 15A photo-1

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

Benergy

Model Number:

24V 15AH

Contact Supplier Request Quote Chat Now

Shenzhen Benergy Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name Benergy

Model Number 24V 15AH

Warranty 1 Years

Specifications

500W charger for lifepo4 battery, lithium battery
suitable for 24V,36V,48V,60V,72V,84V,96V,120V,144V,156V,192V,240V battery.

500W charger for lithium battery, lifepo4 battery packs.

Benergy offer charger for our Lithium battery packs. The standard chargers are mainly for light traction applications like e-bikes,e-scooters etc. We also offer advanced battery chargers with CAN Bus funcation, pls contact us for more information.

Specifications

DC Output

DC Output voltage-maximum: 29.2V

DC Output Voltage-adjust range: None

DC Output Current-maximum: 15A

DC Output Current-adjust range: None

AC Input

AC Input Voltage-range:100-240VAC

AC Input Frequency:50-60Hz:

Mechanical:

Dimensions: 233*120*70mm.

Net Weight: 2.5KG

Operating Temperature: 14 ℉ - 113 ℉ (-10~45 ℃ )

Storage Temperature: -40 ℉ ~158 ℉ (-40~70℃ )

AC Input: Customized, 1.5 meter cable

DC Output: Customerized, 1.5 meter cable.

Charging mode:

Battery Type: 16S/48V Lifepo4 battery

CC (constant current) Stage: 15A

CV (constant voltage) Stage: 29.2V

Cut-Off: 29.2, 0.8A

Safety Standard: CE Listed, UL compliant.

Safety-Europe: EN60335-2-29:2002

Features:

1. Short-circuit protection: Charger O/P cut-off automatically when short circuit.

2. Overload portection: Charger O/P current limited automatically when overload.

3. Reverse polarity protection: Charger O/P cut-off automatically when battery reverse connection.

4. Automatic multi-rate charging fuction: CC, CV, Cut-Off.

5. Parallel operation available: Parallel with battery as DC power supply operation.

6. 2 LED Display: LED1 Red (Power on); LED2 Red (Charging); Green (full).

Operations:

1. Check if your local mains supply conforms to charger's input voltage 110V or 230V. Then connect the charger system to a wall socket strongly.

2. LED1 RED confirmes AC power on, and the LED2 GREEN confirms charger connects well.

3. Connect the plug or DC output cord to battery terminals LED2 light turns to RED, and if goes to GREEN, it confirms battery fully charged.

(N Positive + , L Negative - ; Brown +ve terminal, Blue -ve terminal).

Note: If this charger with a relay for reverse polarity protection, it doesn't have output voltage and current when charger power on but disconnecting with the battery. It will have voltage and current output when it connects with battery. If the charger don't have a Relay for reverse polarity protection, it has output once the power on.

Notices:

1. Charger will turn off automatically if it was not connected to battery for 1-3 minutes after power on, please start it again.

2. This charger is designed for charging lithium battery. Lead acid battery is available after adjustment.

3. The battery may be demaged if LED2 cannot be changed to green after long time charger.

4. Always place the charger in well-ventilated and dry environments.

5. The charger is designed by aluminum housing as itself heat sink, do not cover it avoiding over temperature on the case when charging.

6. Charger should be power on for 2 hours once a month.
