Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Wire > Wire and Cable

Wire and Cable

Name: Wire and Cable
Brand: Henan Joinrise
SKU: 124503155
Availability: InStock

US$ 888 - 888 MOQ: 1 Roll

Key Specifications

Get Latest Price

Steel Grade:

alloy steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge:

1-50MM

Contact Supplier Request Quote Chat Now

Henan Joinrise Mining Equipment Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Shanghai or others

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Steel Grade alloy steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Wire Gauge 1-50MM

Place of Origin Henan, China

Type Other, steel wire rope

Application Rope

Alloy Or Not Is Alloy

Special Use Free Cutting Steel

Model Number Y

Brand Name Henan Joinrise

wirerope

Wirerope with variety model provided by

honest supplier

Henan Joinrise Mining Equipment Manufacture Co., Ltd.

Product Description

Scope of application:

This wirerope is widely applicable in electrical wiring, mining, high-lift hoisting machinery, ship bulding, port etc.

Wirerope description

This type is designed for specail engineering needs, and made of fine hot galvanized steel wire through specail production process. The wirerope is inter-braided with multiple strands into a rope with square or hexagonal and face.

As the center of the end face counteracts the resultant monent. The rope maintains torsion-proof when affected by force, and it greatly reduces corrosion and rust.

Certifications

Product Parameter

Parameters of steel wirerope

Type	Nominal Diameter (mm)	Structure	Weight (Kg/m)	Wirerope Breaking Force(T)			Standard Length (m)
				Strand Structure
				1x19	1x19w	1T25 1T29
YS6-8x19	6	Square8-Strand	0.115	16	17.5		1000
YS7-8x19	7	Square8-Strand	0.185	32	36		1000
YS8-8x19	8	Square8-Strand	0.220	38	40		1000
YS9-12x19	9	Square12-Strand	0.280	50	55		1000
YS11-12x19	11	Square12-Strand	0.480	70	80		1000
YS13-12x19	13	Square12-Strand	0.630	105	120		1000
YS16-12x19	16	Square12-Strand	0.925	140	158		1000
YS18-12x19	18	Square12-Strand	1.150	185	540		1000
YS20-12x19	20	Square12-Strand	1.320			250	1000
YS22-12x1T25	22	Square12-Strand	1.882			320	1000
YS24-12x1T25	24	Square12-Strand	2.034			360	1000
YS26-12x1T25	26	Square12-Strand	2.350			420	1000
YS28-12x1T29	28	Square12-Strand	3.012			480	1000
YS30-12x1T29	30	Square12-Strand	3.320			540	1000
YL9-12x19	9	Hexagon12-Strand	0.297	50			1000
YL11-12x19	11	Hexagon12-Strand	0.480	70			1000
YL13-12x19	13	Hexagon12-Strand	0.630	105			1000
YL16-12x19	16	Hexagon12-Strand	0.925	140			1000
YL18-12x19	18	Hexagon12-Strand	1.150	185			1000
YL20-12x19	20	Hexagon12-Strand	1.320			250	1000
YL22-12xT25	22	Hexagon12-Strand	1.822			320	1000
YL24-12xT25	24	Hexagon12-Strand	2.034			360	1000
YL26-12xT25	26	Hexagon12-Strand	2.350			420	1000
YL28-12xT29	28	Hexagon12-Strand	2.882			480	1000
YL30-12xT29	30	Hexagon12-Strand	3.120			540	1000
YL13-18x19	13	Hexagon18-Strand	0.645	105	120		1000
YL16-18x19	16	Hexagon18-Strand	0.925	140	158		1000
YL18-18x19	18	Hexagon18-Strand	1.198	185	210		1000
YL20-18x19	20	Hexagon18-Strand	1.598	280	300		1000
YL22-18xT25	22	Hexagon18-Strand	1.898			389	1000

Breaking Force:It's a tensile force value when the wirerope is broken. Based on the experiments analysis, the conclusion is that has obvious linear correlation between the breaking force of the steel wire rope and the diameter of the steel wire; the breaking force of rope has obvious linear correlation with the diameter, number of bends, tensile strengty.
