Specifications
48V 80Ah lifepo4 battery pack1.High discharge rate
2.High energy density, deep cycle. Long life
3.CE/ROHS/MSDS
4.OEM
48V 50AH LiFePO4 Battery Pack for electric scooter, electric car, other EV, solar energy storage, UPS, telecom station building . Finished products matched with BMS+iron case (For easy shipping & moving).
Product advantages:
1. Long cycle life (2000 cycles). is several times greater than Ni-MH, Ni-Cd or lead-acid.
2. No toxic, or polluting material. (such as lead, cadmium, mercury) is contained in lithium battery, which is a kind of green battery.
3. High safety. LiFePO4 is an intrinsically safer cathode material than Lithium-ion since exothermic reactions can not occur in batteries based on this material LiFePO4 cells do not incinerate or explode under extreme conditions.
4. Good performance in high-current discharge cycles. We can design different capacity and size according to your demands.
For many applications, our battery systems result in significantly lower total cost of ownership over lead acid because lighter-weight, longer-life batteries means fewer replacements, reduced maintenance and service costs, less shipping and material handling costs, and lower total inventory carrying costs.
Detail Specifications:
Item |
Parameters |
Remark |
|
Nominal voltage |
48V |
|
|
Nominal capacity |
80Ah |
0.2C discharge |
|
Internal Impedance |
<100mΩ |
AC Imp |
|
Max Charge voltage |
58.4V |
|
|
Discharge Cut-off Voltage |
>38V |
|
|
Continuous Charge current |
35A |
|
|
Continuous discharge current |
30A (or set based on your requirement) |
|
|
Max discharge current |
100A(2s) |
|
|
Connection mode |
16S8P |
|
|
Battery box |
Painted iron housing |
|
|
Dimensions |
430* 360*190*mm(L*W*H) |
or customized design |
|
Weight(Kg) |
About 36 Kg |
|
|
Charge/discharge port |
Anen connector |
|
|
charging method |
standard |
0.2C5A×6 hrs.(reference value) |
(CC/CV) |
|
Fast |
0.5C5A×3 hrs.(reference value) |
|
Working temperature |
Charge |
0℃~+45℃ |
|
|
Discharge |
-20℃~+55℃ |
|
Storage Temperature |
-40℃~+40℃ |
|
|
Storage humidity |
5%~90% RH |
|
|
Why choose Benergy as your supplier?
1.Professional lithium-ion battery pack for over 5 years (Since 2009).
2.Experienced R&d team to support.
3.Only make high quality battery
4.Whole battery solution battery+ BMS solution.
5.Offer OEM service for customer small order.
6.Quickly action & respond.
7.Best sale service and good price.
8:All of us,working hard.
Automatical producing, grading and testing process:
Some of our certifications:
Fast delivery by various shipping ways:
Other Applications of Our Lifepo4 Battery:
EV |
Mini E-car, e-bikes, e-scooter, e-motorcycles, Road Sweeper, golf cart, electric wheelchair, startup car battery |
UPS |
Telecom Base station, Lighting, Small Doctor instruments, Stand by Power, Mining lighting, LED torch, Video, Heating garment, data acquisition power, Electric water pump, Road side night warning indicator, laser sensor |
Power tools |
Electric lawn mower, electric drill, electric vacuum cleaner, Electrical tools |
Power storage system |
Solar system, Solar pv system, Solar LED street light,Tidal energy, Wind / solar energy, on & off grid solar system |
And different voltage and capacity is available!OEM orders are welcome !
Please feel free to contact us!
