Help Center1880 Model Toilet Paper Machine
Related Products
high concentration aquapulper |
high frequency vibrating screen |
hydrascreen |
bleacher |
efficient double disc pulp grinder |
Pulp pump |
slag separator |
| pressure screen |
propeller |
vacuum pump |
1880 toilet paper making machine |
| rewinding machine |
| band saw paper cutter |
| sealing machine |
According to the client's raw material, require finished production some equipments need change or add. So
please let me know your raw material, net-paper width, gram paper weight and capacity, if you are intersting
in this machine.
1. Pulp-flowing box: It adopts open-type pulp-flowing box, consisting of pyramid tube, staircase diffuser, distributing roller and box body. Staircase diffusion orifice plate pulp distributor is three-stage diffusion, which made of organic glass and upper and lower lip plates made of stainless steel. The upper lip plates can do full and local adjustment is three-stage diffusion.
2. Fourdrinier part: Wire table is 18000mm. Except draw-out seat made of alumina alloy, table rack is all welded by section steel with 1.5mm stainless steel cladding. Wire part is mainly composed of chest roller, forming board, wire-driving plate, water scrapping board, moisture absorbing box, and vacuum water-absorbing box, vacuum roller, wire-driving roller, electrical wire-tighter, pneumatic corrector, constant-tension wire-tighter, incision needle and margin raising device.
3. Press part: It adopts vacuum absorption injection paper, one streak of vacuum pressing and three streaks of pressing.
4. Drying part: It is set 28 pieces of φ1500mm drying cylinders, including one φ3000mm big cylinder of array type, 6+6+8+1+glueing machine+8 driven by enclosed gear box and lubricated by sparse oil.
5. Driving and control part: It adopts AC frequency conversion speed, drive step by step. Hard tooth surface gear box connected by universal coupling is used, and entire digital closed circle control system is used.
6. Press-polishing and paper reeling: It adopts super press polishing machine and level paper reeling machine.
