Huaxia Paper Making machinery Co., Ltd is a high tech enterprise specialized in designing and manufacturing paper-making equipment, pulping equipment and paper finish equipment.
Established in 1982, Huaxia started manufacturing paper-making equipment in early period in China with strong technology, reasonable designs and scientific quality management systems. Over the past 20 years, our enterprise develops rapidly and our production capacity and production level become higher. We are rewarded as honest enterprise by the government.
Our leading paper machinery products: 600 model, 787 model, 1092 model, 1760 model, 1880 model, 2400 model, 2880 model, 3200 model. We provide accessories and aux equipment and also we can manufacture according to customer’s requirement.
With our superior products, good service, and honesty, we are looking forward to having bright business with customers.
High technology 2880-type fourdrinier multi-cylinder cultural paper machine
The process flows of culture paper:
waste paper or wood pulp →high concentration aquapulper→high frequency vibrating screen→pulp pump → efficient double disc pulp grinder→pulp pump→ thickener → crew propeller→ pulp pump → crew propeller→ pulp pump → centrifugal screen → pulp pump →pressure screen → pulp pump → slag separator →2880 type paper machine →calendar → rewinding machine → band saw paper cutter →marketing
Main machine list
product name |
high concentration aquapulper |
high frequency vibrating screen |
efficient double disc pulp grinder |
thickener |
Pulp pump |
slag separator |
centrifugal screen |
pressure screen |
propeller |
vacuum pump |
2880-type fourdrinier multi-cylinder cultural paper machine |
rewinding machine |
band saw paper cutter |
The technical parametersofthe 2880 long network of multi-cylinder culture paper machine:
Papermaking varieties: Writing paper, copy paper, offset paper;
Papermaking quantitative: 50-100g/m2;
Net paper width: 2880mm;
Rail distance: 3800 mm;
Working speed: 350m/min;
Dynamic balancing speed: 500 m/min;
Transmission speed: 400 m/min;
Design output: 20-100T/D;
Transmission: AC frequency control stepdrive;
Design standards: GB exportequipment
Major equipment structure:
Headbox: It uses the open headbox . It is composed by pyramid pipe,Stepped diffuser,Rectifier roll,Cabinet. Ladder diffusion orifice cloth pulp apparatus is three-level diffusion. And it is made from stainless steel with the upper and lower lip plate of plexiglass.The upper lip plate can be adjustedfully andpartially.
fourdrinier section: The length of network plate is18000mm,network plate bench is all welding steel with 1.5mm stainless steel except for the drawn set of aluminum. Fourdrinier section is consisted of chest roll,forming board,wiper blade,Wet suction boxes,vacuum suction box,Suction couch roll,drive network roll,electric tightnetwork,Pneumatic corrector,tight networkofconstant tension,Cutting water injection,warped edge device.
Press section: It is composed by a vacuum press and three straight press with adopting vacuumpipettecitedpaper.
Drying section: With 28the dryerofφ1500mm,Including a φ3000mmvat,Arrangement of type:6+6+8+1+sizing machine +8,Adoptingclosed gearbox, thin oil lubrication.
Ministryof Power Transmission and Control: It adopts AC variable speed segment transmission, frequency conversion motor, hard gear reducer, the universal coupling join and all-digital closed-loop control system.
Calender and reeling paper: It adopts the super calender and level winder.
