hot sale pe blowing and printing machine
- 50 Set / Sets per Month
- shanghai
- T/T
- High Quality High Speed Rotogravure Printing Machine
- ASY gravure printing plastic film reel machine
- 2 Color 3 Unit Group Rotogravure Printing Machine
- Polyethylene Film Paper Aluminum Foil Rotogravure Intaglio Printing
- auto register rotogravure printing machine high quality high speed multicolor rotogravure printing
- Roll to Roll multi colour rotogravure printing machinery/textile printing machinery/plastic gravure printing machine
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | honghua |
Model Number: | JSY | Usage: | Other, plastic print | Automatic Grade: | Automatic |
Voltage: | 220v | Gross Power: | 21kw | Dimensions(L*W*H): | 6000*130082500 |
Weight: | 2200kg | Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
This machine can blow and print plastic film at the same time with printing in both sides,the material is PE,PP etc.
Main Technical Data
1. Screw: pole | φ45, L/D: 28:1; |
2. Blowing and printing width | 100~350(mm) |
printing width | 420mm; |
3. Film thickness | LDPE: 0.012~0.08mm, HDPE 0.01~0.03mm; |
4. Production capacity | 10~35 kg/h; |
5. Printing speed | 0~40 m/min; |
6. Gravure installation size | length 420 mm, φ75~180(mm); |
7.gear box | High strength hard tooth surface reduction gear box; |
rona | Intellectualized digital corona treatment; |
9.tempreture controler | Digital intelligent temperature controlling system; |
10.total power | 21kw |
11. Total weight | 2200kg; |
12. Overall size(L×W×H) | 6000×1300×2500mm |
Main feature and performance
1. Wide application, several purposes(It can blow HDPE and LDPE, blowing and printing at the same time, or single blowing and single printing);
2. Advanced structure, easy operation, correct overprint, easy maintenance;
3. Saving Raw material, reliable quality. It has following advantages which we compared with same line machines:
a. Bright color, strong fastness;
b. Blowing and printing at the same time, exact overprint;
c. Easy maintenance, reliable and stable quality;
d. Less power consumption, less labor, saving working time, less cost, etc.
