HDMI Signal Amplifier Repeater 4K Ultra Slim Design
The HDMITM Repeater enables to boost the HDMITM signal via HDMITM cable up to 35m at 4K@30Hz. The special design allows the active circuitry to be powered by the HDMITM cable itself that has 5-volts of power running through the HDMITM cable. Plus the gold-plated connectors help improve signal and reduce interference.
* Integrated signal amplifier for extending HDMI cables up to 35m at 4K@30Hz
* Self-powered active circuitry for fast, easy, elegant installation
* Support Full 3D and 4K@30Hz resolution
* Support 340MHz/3.4Gbps per channel (10.2Gbps all channels) bandwidth
* Support 12bit per channel (36bit all channels) deep color
*Support HDCP pass through
* Support Consumer Electronics Control function
* Support uncompressed audio such as LPCM7.1
* Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master AudioTMand Dolby TrueHD).
* Ultra slim design
Note: Dolby is a trademark of Dolby Laboratories.
Signal Input |
HDMI Signal |
HDMI Input /Output Connector |
HDMI Type A 19 pin |
Output Video |
HDMI Signal |
Vertical Frequency Range |
50/60Hz |
Video. Amplifier Bandwidth |
3.4Gbps/340MHz |
Interlaced Resolutions(50&60Hz) |
480i,576i,1080i |
Progressive Resolutions(50&60Hz) |
480p,576p,720p,1080p, 4K@30Hz |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0℃ to 70℃ |
Operating Humidity |
10% to 85% RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90% RH (no condensation) |
Power Supply |
Micro USB Power Cable |
Power Consumption(Max) |
1.5W |
Repeater Unit Cert |
FCC,CE, RoHS |
User Manual |
English Version |
Note:
1. Specification is subject to change without notice.
2. We recommend to add the Micro USB Power cable (included) for 4PETRTN when the HDMI cable can’t draw enough power from the video source.
PACKAGE CONTENTS
1) Main Unit
2) Micro USB Power Cable
3) User Manual
Certificates
Certifications: CE, FCC, HDMI Adopter, REACH, RoHS
