Help CenterHDMI Extender Cat5e x1 60m Wireless Extender
Related Products
-
Hdmi Repeater Manufacturer Cable Length Extends to 35M 1080PUS$ 25.5 - 27.7MOQ: 100 Pieces -
High Quality Home Theater Repeater Support 4K Ultra Slim DesignUS$ 7.7 - 7.9MOQ: 100 Pieces
-
Cat 5e/6 HDMI Extender up to 30meters Mini Repeater Hdmi Extender With Hdmi CableUS$ 1 - 16MOQ: 50 Units
-
HDMI 1080p Output Extender Over Cat 5e/6 Ethernet Cable to 60MUS$ 25.6 - 35MOQ: 50 Pieces
-
HDMI Repeater Extends Cable Length to 35m Support 3D 1080PUS$ 12.9 - 13.8MOQ: 100 Pieces
V1.3 HDMI Extender 60m Over Single UTP with IR
1.0 Introduction
The HDMI Extender lets you extend HDMI audio/video signal by up to 60 meters (196 feet) over single Lan cable. The extender kit includes both the local transmitter and remote receiver units, perfect for point-to-point digital signage applications that require high quality HDMI video. It also works to extend Infrared IR signals from remote controls, ideal for controlling your video source from your video destination. For perfect performance, the extender comes with a reset function on the receiver, which enables user to adjust the signal to best match the cable length.
2.0 Features
* HDMI over single CAT6 cable transmission up to 60m/196ft
* Supports lossless uncompressed A/V signal transmission
* Signal auto adjustment to match the cable length after press ‘RESET’ button on receiver
* Full HD 1080P transmission to make video image more vivid
* IR signal transmission for easy controlling the source device
* Supports 3D video formats
Note: there are 2 RESET on this extender kit, one on ‘Sender’, one on ‘Receiver’.
RESET at Sender: function as restart
RESET at Receiver: function as equalizer
3.0 Specifications
Signal input |
HDMI Signal |
Input Video Signal |
0.5-1.0volts/p-p |
Output video |
HDMI Signal |
DTV/HDTV |
480i/576i/480P/576P/720P/1080i/1080P |
CAT-6 cable |
60m for 1080p |
Vertical Frequency Range |
50/60Hz |
Interlaced Resolutions(50&60Hz) |
480i,576i,1080i |
Progressive Resolutions(50&60Hz) |
480p,576p,720p,1080p |
Limited Warranty |
1Year Parts and Labor |
Operating Temperature |
0℃ to 70℃ |
Operating Humidity |
10% to 85% RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90% RH (no condensation) |
Power Supply |
5V DC |
Power Consumption(MAX) |
5W |
Extender Unit Certification |
FCC,CE, RoHS |
Power Supply Certification |
CE,FCC, RoHS |
Power Adapter Standard |
US,UK, EU, AUS standard |
User Manual |
English Version |
Note:
1. Cable quality affects product performance.
2. The specification is subject to change without prior notice.
4.0 Package Contents
1)Main unit NO.1 Sender x 1
2) Main unit NO.2 Receiver x 1
3) 1 x IR TX cable
4) 1 x IR RX cable
5) 5V DC Power Supply x 2
6) "L" shape nog x 4
7) User Manual
Netural Package : Color Box or As your Design
