Emulex LightPulse 8Gb Single-Port PCIe Fibre Channel Host Bus Adapter LPe12000

Emulex LightPulse 8Gb Single-Port PCIe Fibre Channel Host Bus Adapter LPe12000 thumbnail-1
Emulex LightPulse 8Gb Single-Port PCIe Fibre Channel Host Bus Adapter LPe12000 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Server
Type:
Wired
Contact Supplier Request Quote Chat Now
Shenzhen Hisco Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Hong kong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Server
Type Wired
Kind Internal
Transmission Rate Other, 8.5 Gbps
Interface Type PCI Express
Certification UL CE
Brand Name Emulex
Model Number LPe12000
Place of Origin China

Specifications

1.LPe12000
2.Full New and Original
3.Good Price from China General Agency
4.It is in Stock
5.Global Coverage

LPe12000 Emulex LightPulse 8Gb Single-Port PCIe Fibre Channel Host Bus Adapter



Product Descriptions





Standards




ANSI Fibre Channel:

FC-PI-4, FC-FS-2, FC-FS-2/AM1, FC-LS, FC-AL-2, FC-GS-6, FC-FLA, FC-PLDA, FC-TAPE, FC-DA, FCP through FCP-4, SBC-3, FC-SP, FC-HBA and SMI-S v1.1
           PCI Express base spec 2.0
           PCI Express card electromechanical spec 2.0
           Fibre Channel class 2 and 3
           PHP hot plug-hot swap

Architecture




Single-channel
8Gb/s, 4Gb/s or 2Gb/s FC Link speeds automatically detected
Integrated data buffer and code space memory

Comprehensive OS Support




Widws, Linux, NetWare, Solaris, VMware
Additional support is available from OEMs and partners

Hardware Environments




PowerPC,® SPARC,® x86, x64 and Intel® Itanium® 64-bit processor family

Optical




Data rates: 2.125, 4.25 and 8.5Gb/s (auto-detected)
Optics: Short wave lasers with LC type connector
Cable: Operating at 8Gb/s
       50/125 microns (500MHz*km BW)-up to 50m
       50/125 microns (2000MHz*km BW)-up to 150m

Physical Dimensions




Short, low profile MD2 form factor card
167.64mm x 68.91mm (6.60" x 2.71")
Standard bracket (low profile available)

Power & Environmental Requirements




Volts: +3.3, +12
Operating temperature: 0° to 55°C (32° to 131°F)
Storage temperature: -40° to 70°C (-40° to 158°F)
Relative humidity: 5% to 95% non-condensing
23 degree C wet bulb

Agency Approvals


Class 1 Laser Product per DHHS 21CFR (J) and EN60825-1
UL recognized to UL 60950-1
CUR recognized to CSA22.2, No. 60950-1-03
Baurt-certified to EN60950-1
FCC Rules, Part 15, Class A
ICES-003, Class A
EMC Directive 2004/108/EEC (CE Mark)
    EN55022, Class A
    EN55024
Australian EMC Framework (C-Tick Mark)
    AS/NZS CISPR22, Class A
VCCI (Japan), Class A
MIC (Korea), Class A
BSMI (Taiwan), Class A
EU RoHS Compliant (Directive 2002/95/EC)
China RoHS Compliant
