LPe16000

LPe16000 thumbnail-1
LPe16000 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Server
Type:
Wired
Contact Supplier Request Quote Chat Now
Shenzhen Hisco Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Hong kong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Server
Type Wired
Kind Internal
Transmission Rate Other, 14.025 Gbps
Interface Type PCI Express
Certification UL CE
Brand Name Emulex
Model Number LPe16000
Place of Origin China

Specifications

1.LPe16000
2.Full New and Original
3.Good Price from China General Agency
4.It is in Stock
5.Global Coverage

LPe16000 Emulex 16Gb Single-Port PCIe Fibre Channel Host Bus Adapter



Product Descriptions



Device Type
Host bus adapter
Form Factor
Plug-in card - low profile
Interface (Bus) Type
PCI Express 2.0 x8
PCI Specification Revision
PCI 2.0
Dimensions (WxDxH)
16.764 cm x 6.891 cm
Data Link Protocol
16Gb Fibre Channel (Short Wave)
Max Transfer Distance
125 m
Data Transfer Rate
14.025 Gbps
System Requirements
Linux, Mcrsoft Widws, VMware ESXi, Oracle Solaris
General
Device Type
Host bus adapter
Form Factor
Plug-in card - low profile
Interface (Bus) Type
PCI Express 2.0 x8
PCI Specification Revision
PCI 2.0
Depth
16.764 cm
Height
6.891 cm
Networking
Connectivity Technology
Wired
Data Link Protocol
16Gb Fibre Channel (Short Wave)
Fibre Channel
FC-AL, FC-AL-2, FC-DA, FC-FLA, FC-FS, FC-GS, FC-GS-2, FC-GS-3, FC-GS-4, FC-MI, FC-PH, FC-PH-2, FC-PH-3, FC-PI, FC-PLDA, FC-SB-2, FC-Tape, FC-SP, FCP-4, FCP, FCP-2, FC-PI-2, FC-FS-2, FC-GS-5, FC-PI-4, FC-GS-6, FC-HBA, FC-PI-5, FC-LS-2, FC-SP-2, FC-MJS, FC-SB-4
Data Transfer Rate
14.025 Gbps
Max Transfer Distance
125 m
Features
Full duplex capability, auto-negotiation, manageable, firmware upgradable
Expansion / Connectivity
Interfaces
1 x network - 16Gb Fibre Channel (Short Wave) - LC multi-mode x 2
Compatible Slots
1 x PCI Express 2.0 x8 - low-profile
Miscellaneous
Included Accessories
Low-profile bracket
Compliant Standards
C-Tick, CISPR 22 Class A, RRL, VCCI Class A ITE, EN55024, EN55022 Class A, CISPR 22, CB, ICES-003 Class A, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, FCC Part 15 A, TUV Bauart, BSMI Class A, KCC Class A
Software / System Requirements
OS Required
Linux, Mcrsoft Widws, VMware ESXi, Oracle Solaris
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
55 °C
Humidity Range Operating
5 - 95% (non-condensing)



Standards

General Specifications

  • The LPe16000 series is powered by the XE201 converged fabric controller and consists of an eight-lane (x8) PCIe 2.0 bus (backward compatibility to PCIe 1.0 supported)—the architecture enables all resources to applied to any port that needs it, delivering up to 1 million IOPS on a single-port

Industry Standards

  • Current ANSI/IETF Standards: FC-PI-4; FC-PI-5; FC-FS-2 with amendment 1; FC-AL-2 with amendments 1 and 2; FC-LS-2; FC-GS-6; FC-DA; FC-SP-2; FCP-4; FC-MJS; FC-SB-4; FC-SP; SPC-4; SBC-3; SSC-3; RFC4338
  • Legacy ANSI/IETF standards: FC-PH; FC-PH-2; FC-PH-3; FC-PI; FC-PI-2; FC-FS; FC-AL (2GFC/4GFC/8GFC speeds); FC-GS-2/3/4/5; FCP; FCP-2; FC-SB-2; FC-FLA; FC-HBA; FC-PLDA; FC-TAPE; FC-MI; SPC-3; SBC-2; SSC-2; RFC2625
  • PCIe base spec 2.0
  • PCIe card electromechanical spec 2.0
  • Fibre Channel class 2 and 3
  • PHP hot plug-hot swap

Architecture

  • Single-port (LPe16000) or dual-port (LPe16002)
  • Supports Gen 5 (16GFC), 8GFC and 4GFC link speeds, automatically negotiated
  • Supports up to 2 FC ports at 16GFC max (dual-port model)
  • Integrated data buffer and code space memory

Comprehensive OS Support

  • Widws Server
  • Linux
  • Solaris
  • VMware vSphere
  • Additional support is available from OEMs and partners

Hardware Environments

  • PowerPC, SPARC, x86, x64 and Intel Itanium 64-bit processor family

Optical

  • Data rates: 14.025 Gb/s (1600Mb/s); 8.5 Gb/s (800Mb/s); 4.25 Gb/s (400 Mb/s) (auto-detected)
  • Optics: Short wave lasers with LC type connector
  • Cable: Operating at 16Gb
    • 15m at 16Gb on 62.5/125 μm OM1 MMF
    • 35m at 16Gb on 50/125 μm OM2 MMF
    • 100m at 16Gb on 50/125 μm OM3 MMF
    • 125m at 16Gb on 50/125 μm OM4 MMF

Physical Dimensions

  • Short, low profile MD2 form factor card
  • 167.64mm x 68.91mm (6.60” x 2.71”)
  • Standard bracket (low profile available)

Power & Environmental Requirements

  • Power supply 1.8V, 1.2V, 0.9V
    • Volts: +3.3, +12
    • Operating temperature: 0° to 55° C (32° to 131° F)
    • Storage temperature: -40° to 70° C (-40° to 158° F)
    • Relative humidity: 5% to 95% non-condensing
    • 23° C wet bulb

Agency and Safety Approvals

  • FCC Part 15, Subpart B, Class A (U.S.)
  • ICES-003 Class A (Canada)
  • VCCI Class A (Japan)
  • CE Mark (EU), consisting of:
    C-Tick (Australia)
    • EN55022:2010
    • EN55024:2010
  • AS/NZS CISPR22:2006 Class A
  • CISPR 22:2005+A1 (International)
  • KCC (formally MIC), Class A with latest RRL notices (Korea)
  • BSMI Class A (Taiwan)
  • UL 60950-1:2001 (cURus – U.S.)
  • CSA 22.2 No 60950-1-03 (cURus - Canada)
  • TUV Bauart certified to EN60950-1:2001
  • CB Report and Certificate to IEC 60950-1:2001 (International)
  • Dimethyl Fumarate (DMF) restrictions in packaging, ref. EU Decision 2010/251/EC:
    China RoHS Compliant
    • EU RoHS Compliant (Directive 2002/95/EC)

Added Features

Performance Features

  • Doubling the maximum FC link rate from 8GFC to Gen 5 and enhanced virtualization capabilities, help support IT “green” initiatives.
  • Frame-level multiplexing and out-of-order frame reassembly increases link efficiency and maximizes HBA performance.

Data Protection Features

  • End-to-end data protection with hardware parity, CRC, ECC and other advanced error checking and correcting algorithms ensure data is safe from corruption.
  • Enhanced silent data corruption protection provided by T10 Protection Information (T10 PI). T10 PI provides additional protection against corruption in Oracle Unbreakable Linux environments.

Deployment and Management Features

  • Universal boot capability allows the appropriate boot environment to be automatically selected for any given hardware.
  • Boot from SAN capability reduces system management costs and increases uptime.
  • Detailed, real-time event logging and tracing enables quick diagnosis of SAN problems.
  • Beaconing feature flashes the HBA LEDs, simplifying their identification within server racks.
  • Environmental monitoring feature helps optimize SAN availability.

Management Features

  • The Emulex OneCommand Manager application enables centralized discovery, monitoring, reporting, and administration of HBAs and UCNAs provided by Emulex on local and remote hosts. Powerful automation capabilities facilitate remote driver parameter, firmware and boot code upgrades.
  • Advanced diagnostic features, such as adapter port beaconing and adapter statistics, help optimize management and network performance, while the environmental monitoring feature helps to maintain optimum host-to-fabric connections. In addition to the GUI interface, management functions can also be performed via a scriptable Command Line Interface (CLI) as well as a web browser.
  • OneCommand Manager supports role-based management to facilitate administration of adapters throughout the data center without compromising security. Management privileges can be assigned based on LDAP and AD group memberships.
  • Emulex’s management instrumentation complies to open management standards, such as SMI-S and common HBA API support, which enables seamless upward integration into enterprise storage and server management solutions.
