Amorphous C Core

Physical Properties METGLAS Alloy 2605SA1
Ribbon Thickness (μm) . . . . . . . . . . . . . . . . . . . . . . . .23
Density (g/cm3) . . . . . . . . . . . . . . . . . . . . . . . . . .7.18
Thermal Expansion (ppm/°C) . . . . . …. . . . . . . . . . . .7.6
Crystallization Temperature (°C) . . .. . . . . . . . . . . . . .508
Curie Temperature (°C) . . . . . . . . . . .. . . . . . . . . . . .399
Continuous Service Temperature (°C) . .. . . . . . . . . . .150
Tensile Strength (MN/m2) . . . . . . . . . . . . . . . . . .1k-1.7k
Elastic Modulus (GN/m2) . . . . . . . . . . . . . . . . . .100-110
Vicker’s Hardness (50g load) . . . . . . . . . . . . . . . . . . .900

Magnetic Properties C CORE
Saturation Flux Density (T). . . . . . . . . . . . . . . . . . . . .1.56
Permeability (depending on gap size) . . . . . . . . .VARIABLE
Saturation Magnetostriction (ppm) . . . . . . . . . . . . . . . . .27
Electrical Resistivity (μ.cm) . . . . . . . . . . . . . . . .   130

 ANY SIZE C CORE CAN BE CUSTOM
