Three phase common mode choke cores

About Coilcore

Coilcore is specialized in the R&D and manufacture of  Amorphous cores,Nanocrystallie cores,CT(Current Transformer), Inductors,Magnetic ballasts and Transformers.

Main products are as follows

--Common Mode Filter Chokes

--Split CT

--Current Transformers

--Differential Mode Chokes

--Automotive Chokes(For car audios)

--Magnetic Amplifiers

--PFC Chokes

--Cores and Current Transformers for energy meters(Watt hour meters)

--ELCB (Earth Leakage Circuit Breakers)

--Toroidal transformers

--Magnetic ballasts.

Small cost but more benefits

Coilcore is always ready to provide you with comprehensive solutions on magnetic projects to meet you.

Here are the product descritions

Product Name: Common Mode Chokes Core

1. Feature

1) High permeabilityμi (200KHz) , high L and impedance Z in the high frequence range
2) High saturation flux density(1.2T)
3) High curie temperature(580°C) and excellent temperature characteristics
4) Low remanent flux density Br with DC-tolerance

2.Application

  -- elecommunications
  --  Switched-mode Power supplies
  --  Uninterrruptible Power Systems
  -- Pulsed welding equipment
   -- Power inverter
  -- Wind generators
  -- Frequency Converter

        For common mode chokes, power transformers and ELPB

VAC Vs COILCORE

3.For your reference,the standard parameters  may vary according to your specifical  -- ly designed turns and coils diameter of the transformer. We could design and manufacture the suitable cores according to your exact requirement.

 You are more than welcome to contact us for any questions and doubts!

For more detail product information,please enter our offical website
