A3 size laser stamp engraving machinemuliti function,can make stamp and also can engrave.flat or cylinder engraving
in store
A3 size laser stamp engraving machine
Brief introduction:
TJ340 laser engraving and cutting machine is used specially for the nonmetal art crafts, gifts and the engraving of bamboo products. The mechanical structure of the machine is strong. The electrical ability is stable, the engraving speed is high, and the precision is good. The machine can engrave beautiful pictures, peoples’ photos on the surface of many materials of different size of materials. It can also engrave many signs, marks.
A3 size laser engraving machine
Specification:
Name: |
TJ340 |
Processing area |
300*400mm |
Laser power |
40W/50w |
Laser type: |
Co2 glass laser tube |
Dimension: |
1100mm*920mm*620mm |
Engraving speed |
1-6000mm/min |
Cutting speed |
1-1000mm/min |
Cutting thickness |
0-20 Plexiglas (others determined by materials) |
Resolution ratio |
≤0.0125mm |
Interface: |
USB |
Minimum shaping character |
letter 0.8mm, Chinese 2mm |
Support graphic format |
DST, PLT, BMP, DXF |
Gross power |
1000W |
Driving mode: |
DC0.8A 24V stepper motor |
Cooling mode: |
Circulation water cooling |
Working voltage: |
AC220V/50HZ or 110V/60HZ or depend on customer |
Packing: |
wooden box |
Guarantee time: |
1 year, laser tube 3 months |
Operation: |
Video to tell customer how to operate the machine |
A3 size laser engraving machine
Applicable materials:
Non-metal materials such as acrylic, double color board, Plexiglas,
Common glass, bamboo and wood, rubber, marble, granite and tiles, leather cloth etc.
Applicable industries:
Advertising industry, Billboards, artistic gifts, crystal ornaments, paper-cut, bamboo
and wooden product, garment and leather, embroidery, decoration and upholster industry.
Functions
1. multi function type electronic lifting table, can engrave and cut one whole piece of seal material, more suitable for more kinds of nonmetallic seal engraving. With widely use.
2.DSP separate control system, with the advanced continue engraving after power off, prevent wasting material. Higher engraving speed, precision, can work off line. Easy operation and save computer resources.
3.Forcible water break protector, can avoid loss from no water in laser tube.
4.Support plt, bmp, dxf and more exporting type, can design any kinds of drawings and character
5.Exhaust smoke, dust removing, blowing protecting
6.Adopt famous laser system,laser power can be adjusted at any time, long lifespan.
Samples:
engrave on flat material, wood/bamboo
A3 size laser engraving machine
purchasing guids:
1).flat engraving size
2).seal size you want to engrave
3).need to engrave on cylinder, which kind? there are 2 kinds rotary
4).need sparts parts except the parts follow with machine for free(3 reflect mirror,1 lens,1 laser tube,1 software)?
After sale service
1).whole machine for 1 year,except for consumable parts(mirrors,laser tube and power,belts)
2)during guratee term, can change new parts for you
exceed term,send you parts in cost price.
3)can provide on-site installation and debugging or study in our factory
4)24 hours on line for you
