50w Diode Side Pumped Laser Marking Machine
Introductions
The diode side-pumped TJ-DP50 is configured for fast speed, high precision laser marking. Special features are the excellent beam mode and free of maintenance. It is the economical choice for marking on fine metal parts, electronic components, high strength alloys, medical instruments, jewellerys and decorations, etc.
Feature
1. Our TJ-DP50 Adopts famous-brand semi-conductor module, beam quality good, and laser power is stabile, life time over 10k hours.
2. Sharp laser beam, high speed and precise marking, beam stable and reliable, low processing costs.
3. Software: with red preview, mirror marking, graphical alignment, hierarchical set parameters functions.
4.With professional constant temperature water cooling system, 24-hour continuous working is reliable. Be applicable to production lines.
5. Rotary worktable system is optional, thus, accomplish marking on cambered surface.
6. Under WINDOWS interface, compatible with files outputted from software such as CORELDRAW, AUTOCAD, PHOTOSHOP etc. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font.
7.No consumable
8.Stability: the use of water cooling structure, integrated design, the output power fluctuation is less than 2%.
Applicable material:
Metals, oxides and alloys, ABS, epoxy resin, ink etc.
Applicable field:
The machine can be used in components of automobile and motorcycle, astronautic apparatuses, chips of integrate circuit electronics, packages of food, drink and cigarettes, keys of mobile phone, batteries, electric apparatuses, fittings and peripheral equipments of computer, ironware tools, stainless steel wares, electric products, communication products, medical devices, sanitation, cleaning and bathing wares, clocks and watches, jewelries, industrial bearings, electric wire and cable, garment.It can mark both words and graphs.
Technicals
Model TJ-DP50
Original of laser: China
Laser output power ≤ 50W
Laser wavelength of 1064nm
Beam quality m2 <6
Laser repetition rate:≤ 50KHz
Marking scope:100mm*100mm (A optional)
Optional engraving area :70mm*70mm /150mm*150mm
Engraving depth: ≤ 0.20mm
Total power: 2.5KW
Minimum width 0.015mm
Repeatability ± 0.005mm
Linear speed ≤ 7000mm /s
System Dimensions (L * W * H)
Host system size 1220mm*650mm*1200mm
Precision cooling system thermostat ±1/cycle chiller
