Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > 10oz Cup Machine ,10oz Paper Cup Machine

10oz Cup Machine ,10oz Paper Cup Machine

Name: 10oz Cup Machine ,10oz Paper Cup Machine
Brand: BEST
SKU: 124347307
Availability: InStock

10oz Cup Machine ,10oz Paper Cup Machine thumbnail-1

10oz Cup Machine ,10oz Paper Cup Machine photo-1

US$ 7,500 - 15,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New, New

Product Type:

Paper Cup Machine

Processing Type:

Paper Folding Machine

Contact Supplier Request Quote Chat Now

Ruian Best Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Type Paper Cup Machine

Processing Type Paper Folding Machine

Place of Origin Zhejiang, China

Brand Name BEST

Model Number JBZ

Voltage 380V

Power(W) 4KW

Dimension(L*W*H) 2700*1300*1700MM

Weight 1200KG

Certification Other, CE, CE

Warranty 1years

After-sales Service Provided Engineers available to service machinery overseas

Equipment Name : 10oz paper cup machine

2.Description:

JBZ series paper cup forming machine is a multi-station automatic forming machinery, it is through the automatic paper

feeder (fan-shaped after printing paper), sealing (ultrasonic sealing paper cup wall or hot sealing ), oiling (top mouth

lubrication), red bottom (from roll paper automaticly cutting), heating, continuous process of knurling (bottom of the cup

seal), curling, and unloading cup collection, and a photoelectric detection, fault alarm, counting and other functions.It is

an ideal equipment for paper tea cups, paper coffee cups, advertising cups and market paper cups, ice cream paper cups

or other the disposable cone-shaped food paper containers.
JBZ series paper cup forming machine is easy to operate (a person for one machine), stable performance, small footprint,

high efficiency.It is a preferred venture projects.

3.Technical Specification :

Model	JBZ-A12	JBZ-S12	JBZ-S22	JBZ-S32
HS. Code	8441309000	8441309000	8441309000	8441309000
Paper Cup Size	2.5--12oz	2.5--12oz	12-22 oz	20-32 oz
Raw Material	1side PE coated paper	1side or 2side PE coated paper	1side or 2side PE coated paper	1side or 2side PE coated paper
Suitable paper weight	135--250 gsm	170-380 gsm	170-380 gsm	170-380 gsm
Rated Productivity	40---50 pcs / Min	40---50 pcs / Min	30-40pcs/Min	30-40pcs/Min
Power	3.5kw	4.5kw	5kw	5kw
Power Source	220V/380V 50Hz	220V/380V 50Hz	220V/380V 50Hz	220V/380V 50Hz
Machine weight	1200kg	1200kg	1600kg	1600kg
Working Air Source	0.4MPa, Air Out-put: 0.6m³/min	0.4MPa, Air Out-put: 0.6m³/min	0.4MPa, Air Out-put: 1m³/min	0.4MPa, Air Out-put: 1m³/min
PACKING SIZE	2700 x 1240 x 1700 mm	2700 x 1240 x 1700 mm	3030 x 1300 x 2100 mm	3030 x 1300 x 2100 mm
Electric Control Box Size	750 x 570 x 1070 mm	750 x 570 x 1070 mm	750 x 570 x 1070 mm	750 x 570 x 1070 mm

4.Samples:

5.Paper cup machine Big Production Show:

6.Cutting Machine Matched for Paper Cup Machine:

7.Paper Cup Machine Moulds :

9.Cover machine matched ( paper cover machine and plastic

cover machine).Both machine we have produce ,please

contact with us if you want to know more about it .

9.Export Standard Wooden Box

10.Compare to other supplier , our advantages as follow :

a.We are have biggest production

b.80%of our paper cup machines are for export , so our machine is following closely to quality.

C.We have more experience for others for the moulds production .

d.delivery time fast.

F.Faithful to all of our customers.

G.Price reasonable.

11.Certificate :

QC Team:

More than 20 persons to check the machine's quality,every machine need 1 week to make adjustment,ensure 100% qualitative product.

Contact:

We will reply you by Email or skype. Telephone within 24 hours,

you can call us anytime if you have any problem of our production.

Shipment:

We will keep tracking with the container until clients receive it.

40HQ,40GP,20FT(LCL,FCL)

Remeber we are RUIAN BEST MACHINERY CO.,LTD , We are strive to achieve quality best , service best ! You are welcome to purchase our equipment!
