Mortar Spraying Machine for Dry Mixed Mortar
Description
RISEN RX30 is a screw pump. It is a continuously working mixing machine, equipped with small air compressor, water pump, flow meter, to spray the dry ready-mixed cement mortar, etc. This machine permits the easy and comfortable transport due to its small and handy dimensions and low weight.
Requirement on the materials:
To have a perfect mortar spraying, the diameter of the sand shall not be too big. The max. sand size is 2mm. And, the cement/sand ratio shall be ≥ 1:3
Application
All pumpable dry ready-mixed mortars or materials, such as Cement mortars, Lime plasters, Gypsum plasters, Masonry mortars, Insulating plasters ,Self-leveling floor screeds,etc.
Feature
- The integrated machine with mixer, self-suck water pump, mini compressor and rotor/stator pump
- The continuously mixing and pumping machine
- Small and handy dimension and low weight, quickly and easily transport even in the most confined spaces.
- The rotor/stator pump ensures the material is pumped and sprayed out continuously and evenly.
- The machine always works with efficiency and silence
- With air valve remote-control function
- The machine consists of portable units, permitting easy to operate and take maintenance and easy to use in any circumstance.
Technology Description
Rated Output |
30 L/min |
Rated Working Pressure |
3 MPa |
Total Power |
8.5Kw |
Main Electric Motor |
3Phase,380volt,5.5 Kw |
Rev.of Rotor |
380 RPM |
Rated Air Output |
250L/min |
Water Pump Rated Output |
700L/h |
Max.Conveying Dist. |
50m |
Hopper Capacity |
120L |
Loading Height |
1000mm |
Conveying Hose ID. |
25/32mm |
Air Hose ID. |
13mm |
Overall Dimension(LxWxH) |
1240×680×1550mm |
Weight |
280 kg |
