Specifications
sawdust drying systems1.suit for different moisture sawdust
2.25 years experience.
3.ISO CE
4.Different capaci
sawdust drying systems
The sawdust drying systems can drying different moisture content sawdust under 12%.the raw material size should less than 5mm.
Working principle of sawdust drying systems
The drying machine for sawdust is equipped one fuel boiler, inlet, steel pipe, exhaust blower (fan), cyclone. Wet materials are input into the hopper. The fuel boiler generates hot air which mixes with wet materials and thenis sucked into the pipes by the exhaust blower (fan) quickly. And then hot air is flowing and going though
the curving pipes and buffer(drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are expelled out by the exhaust blower (fan).
Capacity of the sawdust drying systems
Model sawdust drying systems |
Power |
Capacity |
Weight |
Note |
YHQ-200 |
4KW |
300-400 |
1000kg |
20-40% to 8-12% |
YHQ-400 |
5.5+1.5KW |
700-800 |
1500kg |
20-40% to 8-12% |
YHQ-800 |
11KW |
1100-1200 |
2500kg |
20-40% to 8-12% |
More picture of different capacity sawdust drying systems
1100-1200KG/H sawdust drying systems
700-800KG/H sawdust drying systems
300-400KG/H sawdust drying systems
packing of sawdust drying systems
Attention:
The final sawudst can be used for the wood pellet or the wood briquettes directly.
We also provide different capacity wood brqiuette machine and wood pellet machine.
Small wood briquettes making line.
Small wood pellet making line
