Specifications
drying machine for sawdust1.suit for different moisture sawdust
2.25 years experience.
3.ISO CE
4.Different capaci
drying machine for sawdust
The drying machine for sawdust can drying different moisture content sawdust under 12%.the raw material size should less than 5mm.
Working principle of drying machine for sawdust
The drying machine for sawdust is equipped one fuel boiler, inlet, steel pipe, exhaust blower (fan), cyclone. Wet materials are input into the hopper. The fuel boiler generates hot air which mixes with wet materials and thenis sucked into the pipes by the exhaust blower (fan) quickly. And then hot air is flowing and going though
the curving pipes and buffer(drying chamber) of dryer, thus wet materials is finished to dry, and the dried materials are expelled out by the exhaust blower (fan).
Capacity of the drying machine for sawdust
Model drying machine for sawdust |
Power |
Capacity |
Weight |
Note |
YHQ-200 |
4KW |
300-400 |
1000kg |
20-40% to 8-12% |
YHQ-400 |
5.5+1.5KW |
700-800 |
1500kg |
20-40% to 8-12% |
YHQ-800 |
11KW |
1100-1200 |
2500kg |
20-40% to 8-12% |
More picture of different capacity drying machine for sawdust
1100-1200KG/H drying machine for sawdust
700-800KG/H drying machine for sawdust
300-400KG/H drying machine for sawdust
drying machine for sawdust packing
Attention:
The final sawudst can be used for the wood pellet or the wood briquettes directly.
We also provide different capacity wood brqiuette machine and wood pellet machine.
Small wood briquettes making line.
Small wood pellet making line
