Help CenterHG325 Steel Welded Tube Machinery
Related Products
-
HG377 Tube Shaping MachineryUS$ 40,000 - 700,000MOQ: 1 Set -
Steel Welded Tube Roll Forming MachineryUS$ 40,000 - 70,000MOQ: 1 Set
-
Tube Shaping MachineryUS$ 44,444 - 444,444MOQ: 1 Set
-
ERW20-660 Welded Pipe MillUS$ 44,444 - 777,777MOQ: 1 Set
-
ERW114 Pipe Production LineUS$ 4,000 - 70,000MOQ: 1 Set
Specifications
Commodity: steel welded tube machinery1,Pipe OD:140-325mm
2, thickness:4-12.7mmmm
3, length:6-12m
Commodity |
Steel welded tube machinery |
Round Pipe Size(mm) |
140mm - 325mm |
Pipe Thickness (mm) |
4mm-12.7 mm |
Square Pipe Size(mm) |
90mm*90mm-250mm*250mm |
Pipe Thickness (mm) |
4mm-12 mm |
Material |
Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80 |
Pipe Length(m) |
6 -12m |
Length Tolerance(mm) |
±3mm |
Line Direction |
right or left(from operator's side) |
Production Speed(m/min) |
40m/min |
|
|
Technical Flow |
Scroll up→ Uncoil→ Flattening→ Cutting head, tail→ Strip Steel head-tail butt welding→ Looping storage→ Forming→ High-frequency induction welding→ Removing external burr→ Cooling→ Cutting→ Checking & Collecting→ Binding→ Accessing Warehouse. |
Tube Bottom Pass line/ Line Power/ Electricity Input Power etc. |
Belong to confidential information and detail parameters will be known in the quotation list. |
