Help CenterOutdoor Led Billboard P10 Full Color Led Display Screen
Related Products
-
P6 Outdoor Smd Led Display VideoUS$ 1 - 5MOQ: 2 Square Meters -
GOOD NEWS 2015 Hot Sale And High Quanlity P7 Outdoor Full Colour Led Display ModuleUS$ 1 - 1,500MOQ: 5 Square Meters
-
Hot Promotion And High Quality With Competitive Price Outdoor P6 LED Display ModuleUS$ 1 - 2,100MOQ: 5 Square Meters
-
China Hot Products Waterproof Outdoor Full Color P10 LED ScreenUS$ 640 - 675MOQ: 5 Square Meters
-
Electronic p7 Led Board Display With Outdoor Full Color 7mm Led DisplayUS$ 1,280 - 1,290MOQ: 5 Square Meters
| P10 outdoor 3 in 1 technical parameters | ||
| Unit ModuleUnit Module | Item | Parameter |
| Model Number | P10-16S | |
| Pixel pitch | 10mm | |
| Pixel Density | 10000dots/m² | |
| Pixel configuration | 1R1G1B | |
| Package mode | SMD3528 | |
| Pixel resolution | 32dots(W)*16dots(H) | |
| Max Power consumption | 16W | |
| Weight | 0.27kg | |
| Drive type | Constant drive | |
| Scan mode | 1/16scan | |
| Port type | HUB75-B | |
| Brightness of white balance | ≤2500cd/m² | |
| Module size | 320mm*160mm | |
| Dimension | 640mm*640mm | |
| waterproof | IP65 | |
| Quanty of Module | 8 | |
| Power supply | 5V/40A | |
| Pixel per cabinet | 32*16 | |
| Best viewing distance | 8M-26M | |
| Best viewing angle | 160°(W)120°(H) | |
| temperature |
storage:-35℃-+85℃ working:-20℃-+50℃ |
|
| operation humidity | 10%-95% | |
| Thickness | 85mm | |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 300W/S | |
Features of led screen
1,there are two kinds of types about led screen:indoor led screen and outdoor led screen.
case frame is indived into four kinds:simplified iron case,standard case,aluminum case and die casting aluminum case.
Simplified iron case without door ,used in indoor generally.
Standard iron case have door and waterproof, used in outdoor.
Aluminum case and die casting aluminum case are used in indoor stage or outdoor rental.
Ps: above metioned cases only standard iron case have fan.
Video CPU:CW-3000 price:4700RMB/pc
The led screen is consisited by case frame ,power,power line,FPC,module,receiving card,sending card.fan.
IP65:ingress protection 65 means waterproof sunscreen and moistureproof.
Outdoor led screen max power consumption300-500w/s
Indoor led screen max power consumption 250-300w/s
Outdoor led screen max brightness:7500cd/m²
Indoor led screen max brightness :3500cd/m²
Brightness and waterproof are main different between indoor and led screen and outdoor led screen.
Led screen aging test:48hours
Led screen should power off more than 4 hours in a day.
Led screen operation method:computer cable control,WIFI and USB.
package detail:wood case or flight case
delivery detail:7-14days
GuangZhou Chengwen photoelectric Technology Co,.Ltd,is a independent research and development,specializing in the production stage,stage lighting equipment and sales of high-tech enterprises.The company was built in 2012,it has already been widely applied in each domestic domain and has obtained consistent high praise from people of all walks of life both home and abroad by relying on its advanced technology,Company products are exproted mainly sell like hot cake s in :South Korea,Russia,India,Thailand,canbodia,Burma,Vietman,Pakitan,Malaysia and africa,adn many other countries.Hace agent distribution throughout the provinces regional market in china.its remarkable quality ,its stable performance and its first-class service.from the video system ,theathers,to rented performance-it`s brands ChengWen hace already been regarded as the first choice to many important activities,large -scale cultureal parties,dance theaters,telecision stations and other entertainment places,simultaneously,it also continues the OEM sevice for the world -known brand.
We came out each producing procedure according to ISO9010:2000 international quality control system in order to achievezero flaw in product quality All of our products has passed relative quality restriction aging test,and has received CE,BL and the CAS quality authentication.
We hace an ideal dream :The stage will be more splendid with "Cheng Wen"lights
Payment terms
T/T WESTERN UNION
30%T/T in deposit,balance 70% T/T.
dear all,
if you are intersted in our product,just send inquiry to us,we and our customers should know our engineerscan solve any qestion which is about our product.
