Home > Products > Uninterruptible Power Supply UPS > HP-C6K-20K high frequency true online UPS/low price best service in China

HP-C6K-20K high frequency true online UPS/low price best service in China

FOB Price

US$ 400 - 1,300 / Piece

1 Piece(Min. Order)

Port Foshan
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Greentechy
Model Number	HP-C6K-20K	Phase	Other, Single phase and Three phase
Protection	Other, Short Circuit, Overload	Weight	35-95
Output Voltage	220/230VAC	Type	Other, On-line, High frequency online indoor UPS
Application	Other, All kinds office equipment

Product Description

Specifications

1. True online double conversion
2. Controlled by DSP+CPU
3. DC start & Auto restart function
4. Adaptable with generator

Features:

1.True on-line double conversion technology
2.Highest reliability and maximum performance for power parallel and redundancy N+X
3.Super wide input voltage range and fully AVR
4.High input power factor
5.Zero transfer time
6.Controlled by fully digitized DSP+CPU
7.Self diagnosis and protection
8.Protection against all types of power problems
9.Miniaturization design,save on invaluable space
10. No add-on CNTL unit required for future expansion
11.Advanced IGBT power components,which enhancing the overall reliability and conversion efficiency
12.Equipped with Maintenance Bypass Switch to achieve online maintenance
13.Smart local and distance monitoring capability with RS232 port,and compatible with SNMP
14.LCD display with information available at a glance

Model: HP-

E6022M

E6022L

E1032M

E1032L

E1034L

E1534L

E2034L

C6022M

C6022L

C1032M

C1032L

C1034L

C1534L

C2034L

Max.capacity(VA/W)

6KVA

10KVA

15KVA

20KVA

Input

Input wiring

Single-phase line two+Ground line

Three-phase line four+Grround line

Voltage range

176--276VAC

304--478VAC

Frequency range

46--54 Hz

Power factor

≥0.95

Output

Voltage

220VAC±2%

Frequency

Input synchronized the supply frequency(line mode), 50 Hz±0.1%(Battery mode)

Power factor

0.7

Current crest artio

3:1

Wavefrom

Sine wave

Overload capacity

110%-150% load, change to bypass after 3 seconds, 150% load holds 300ms.

Standard backup time(full or halfoad)

>7′/20′

>5′/30′

Efficiency

>91%

>90%

Voltage of the battery

240VDC

Transfer time

Zero interruption

Automatic Bypass

Integrated

Indicator

Indicates load/battery capacity,UPS running states etc

Audible alarm

Battery discharge

Sounding every 4 seconds when mains fails

UPS Abnormal

Beeping continuously

Parellel Port (option)

Up to three units in parallel for power redundancy ang load sharing

Communication interface

RS232+SNMP(option)

Operating environment

Temperature

0--40

Humidity

20%-90%,No condensate

External/Shipping Size

(W×D×H)

260×570×720/450×705×1000

Net/Gross weight(kg)

84/94.5

35/52

84/94.5

35/44

35/48

55/72

Option

(SNMP Adapter),(Battery cubicle),(Parallel Port),(Maintenance Switch)
