Home > Products > Solar Power Systems > 3KW,4KW,5KW,6KW,10KW Environment Friendly solar panel system off grid

3KW,4KW,5KW,6KW,10KW Environment Friendly solar panel system off grid

FOB Price

USD $3,000 - $7,000 / Set

1 Set(Min.Order)

Supply Ability 3000 Set / Sets per Month
Port Foshan
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	Greentechy
Model Number	GT-5KW Solar	Specification	Normal
Application	Commercial	Output Voltage (V)	110/120/220/230VAC
Load Power (W)	5KW	Solar Power (W)	5KW
Work Time (h)	1-24hrs

Product Description

Specifications

1) Low cost,Long lifetime
2) Energy saving,high efficiency
3) Eco-friendly,low consumption
4) Maintenance free

5KW off-grid solar power system for home/company,office,building,hotel,villa,CCTV etc...

(1) Reliability

Solar power systems seldom break down even in harsh weather conditions and hostile environment, so they are often applied to occasions that demand highly reliable power supply without increasing system construction cost.

(2) Durability

Solar power systems can generate electricity for 25 continuous years or more.

(3)Autonomous Power Supply

Off-grid PV systems can reduce the inconvenience and other bad effects which utility grid failure may bring to the users.

(4) Modularized Flexibility

PV modules are highly adaptable, allowing the users to choose and adjust the system's scale as per their need.

5000W solar power system
Load	Model	Load power		Unit	Work time (one day)		KWH (one day)
Light		11W		8	6		528Wh
Computer		100W		2	5		1000Wh
Printer	laser	250W		1	1		250Wh
Fax	Ink	150W		1	8		1200Wh
Fridge	150L	100W		1	24		2400Wh
Washing machine		300W		1	1		300Wh
Microwave		1000W		1	1		1000Wh
Air conditioner	1.5 pair	1200W		1	5		3000Wh
Tv receiver /VCD		25W		1	6		150Wh
Tv	21 inch	95W		1	6		570Wh
Water pump		400W		1	1		400Wh
Total		3808W					10798Wh
5000W solar power system
System name	Total capacity		Model			Power		Unit
Solar panel	3360WP		Mono-210W			210W		16
Solar battery	400AH/96V		12V200AH			200AH/12V		16
Controller	30A/96V		96VDC/30A			30A/96V		1
Inverter	5000W		96VDC/5KW			5000W/96V		1

Product features

- CE, ROHS, TUV approved.

- High conversion efficiency, high-transmission rate.

- Energy saving, environmental-friendly.

- Advanced technology, strict quality control system.

- Easy installation, safe operation, free maintenance.

- NO MOQ, fast delivery time, long service life.

- Quality in priority, clients the upmost

Afford facility:

For personal household use, villa, school, hospital, village and backwoodsman place

Application:

Lighting, TV , radio, street lights, water pump, computer, refrigerator, microwave oven, washing-machine, printer and fax machine, etc.

Question:What can be included for this system?

Answer:This Off grid system includes:solar panels+ solar inverter+ solar charge controller+solar battery

Question:What's the advantage for this solar system?

Answer:1.Steady operating 2.The most advantage:On grid energy backup(not means sell electricity,just backup) 3.CE Certified 4.Easy installation according to our instructions fessional parts supply

Question:How to place and install them before we use?

Answer:The system can be put on ground outside house,but must be kept away from water or spray.And the solar panels must be placed away from shadow,the less dust the better in the air.And the solar panel must be placed to a certain angle(20-45 angle) which will be faced directly to the sun

Question:how about the lifetime?

Answer: Solar panel warranty is 10 years.The life span for solar panel is 25years.

System Application:

1,Living house and home building;

2.Office building ,factory and warehouse

3.Shopping mall,venue,stadium and so on

4.Power station,field operation and some huge engineer construction
