Place of Origin
Guangdong, China
Brand Name
JDD
Model Number
SSCW-013
Type
Other, self-closing
Material
Other, PET monofilament and multifilament
| Silent braided wrap |
| JDD-SSCW silent braided wrap is woven by Polyester monofilament and Polyester multifilament. The special structure offers excellent reduction of noise. Side-entry design makes it easy to install, remove and reuse for wire harnesses or cables, especially where it is installed in difficult areas to reach such as door panels or dashboards. This kind of sleeving achieves the same protection function as other common expandable sleeving products adding the noise reduction. |
| Technical data | |
| Material | PET monofilament and multifilament |
| Operating range | -50℃-+150℃ |
| Melt point | 240±10℃ |
| Flammability | VW-1 |
| Standard color | Black |
| Certificate | ROHS,Halogen free |
| Cutting tool | Hot knife |
| Datasheet | ||||
| Part No. | I.DI | Overlap% | Max. bundle Dia. | PackingL |
| SSCW-005 | 5 | 25.0% | 6 | 200 m |
| SSCW-009 | 9 | 10 | 100 m | |
| SSCW-013 | 13 | 14 | 50 m | |
| SSCW-019 | 19 | 20 | 25 m | |
| SSCW-025 | 25 | 26 | 25 m | |
| SSCW-032 | 32 | 33 | 25 m | |
| Unit:mm | ||||
Notes:
- The part No. will be followed by BK, GR and so on to indicate the color of the wrap.
- Special packing, sizes and colours can be supplied upon request.
- All numerical data are average or typical values, not including customized sizes.
The product is most commonly used on wires harnesses, cable assemblies, flat ribbon cable, tubing and hoses providing a tough, durable protection and a reduced noise level in the automotive applications, railway, industrial machinery and similar fields.
