Description:
FR1100 is consists of modified polyester monofilament. It offers lightweight, flame retardant and excellent abrasion resistance. The high expansion ratio allows it could be easily cover through the large cable connectors.
Application:
It’s used to protect the automotive rubber hose, wire harnesses against mechanical abrasion, fire resistance and fluid resistance.
Technical data:
Material: Polyester
Working temperature: -50℃~+150℃
Melting point: 240°C±10℃
Flammability: UL VW-1, FMVSS302
Color: Black and grey
Cutting tool: Hot Knife
Approval: UL, ROHS, REACH, Halogen Free
Dimensions:
Part No. |
Nominal size (W) |
Expandable Range |
Packing (L) |
||
Inch |
mm |
Min.(I) |
Max.(O) |
||
FR1100-003 |
1/8'' |
3 |
1 |
6 |
1000 m |
FR1100-006 |
1/4'' |
6 |
3 |
9 |
500 m |
FR1100-008 |
5/16'' |
8 |
5 |
16 |
350 m |
FR1100-010 |
3/8'' |
10 |
7 |
19 |
350 m |
FR1100-012 |
1/2'' |
12 |
8 |
24 |
350 m |
FR1100-016 |
5/8'' |
16 |
10 |
27 |
250 m |
FR1100-019 |
3/4" |
19 |
14 |
30 |
200 m |
FR1100-025 |
1" |
25 |
18 |
35 |
200 m |
FR1100-032 |
1-1/4" |
32 |
20 |
50 |
150 m |
FR1100-038 |
1-1/2" |
38 |
30 |
60 |
100 m |
FR1100-045 |
1-3/4" |
45 |
35 |
75 |
100 m |
FR1100-050 |
2" |
50 |
40 |
80 |
100 m |
FR1100-064 |
2-1/2" |
64 |
45 |
105 |
100 m |
FR1100-076 |
3" |
76 |
64 |
120 |
100 m |
Unit: mm
