Automotive sleeve-Nylon 66 braided expandable sleeving
- 2000000 Meter / Meters per Month
- Shenzhen
- NQ core drill bits,diamond bits
- Cost effective Concrete thin wall core bits,diamond tipped core bits
- Long life CSC-120 crawler mucking loader ,tunnelling machine
- Thin Wall Wet Diamond Core Drill Bits
- R32 51mm EXX TC tipped Cross bits,drilling bits,taper bits
- H22 tapered dill steels for small hole drilling
Product Details
Place of Origin: | Guangdong, China | Brand Name: | JDD TECH | Model Number: | FR1200 |
Type: | Other, sleeve | Material: | Other, Polyamide 66 |
Product Description
Description:
FR1200 nylon expandable sleeving is made of nylon 6.6 monofilament which offers excellent performance of abrasion resistance, it is tough, flexible, light weight and resistant to trapping water, heat and humidity, the open-weave construction enables each size to expand to fit several sizes and shapes.
Application:
It is most commonly used to protect wire harnesses, cable assemblies, water hose, aircondition pipes, fluid pipes in automotive, railway, electronic, and telecom industry.
Technical data:
Material: Polyamide 66
Working temperature: -60℃~ +160℃
Flammability: FMVSS302
Melting point: 256℃ ± 5℃
Color: Black and grey
Cutting tool: Hot Knife
Approval: ROHS
Dimensions:
Part No. | Nominal size (W) | Expandable Range | Packing (L) | ||
Inch | mm | Min.(I) | Max.(O) | ||
FR1200-003 | 1/8'' | 3 | 1 | 6 | 1000 m |
FR1200-006 | 1/4'' | 6 | 3 | 9 | 500 m |
FR1200-008 | 5/16'' | 8 | 5 | 16 | 350 m |
FR1200-010 | 3/8'' | 10 | 7 | 19 | 350 m |
FR1200-012 | 1/2'' | 12 | 8 | 24 | 350 m |
FR1200-016 | 5/8'' | 16 | 10 | 27 | 250 m |
FR1200-019 | 3/4" | 19 | 14 | 30 | 200 m |
FR1200-025 | 1" | 25 | 18 | 35 | 200 m |
FR1200-032 | 1-1/4" | 32 | 20 | 50 | 150 m |
FR1200-038 | 1-1/2" | 38 | 30 | 60 | 100 m |
FR1200-045 | 1-3/4" | 45 | 35 | 75 | 100 m |
FR1200-050 | 2" | 50 | 40 | 80 | 100 m |
FR1200-064 | 2-1/2" | 64 | 45 | 105 | 100 m |
FR1200-076 | 3" | 76 | 64 | 120 | 100 m |
Unit:mm
