QF AUTOMATIC FOLDER GLUER
- 100 Set / Sets per Month
- China port
- T/T
- Infrared and circulating air dryer Printing Ink Tunnel Oven Machine
- big size Automatic screen printing machine for sheet with automatic blanking
- Printing Ink Tunnel Oven Machine
- Ozone-free energy saving and environmental protection LED uv curing machines
- Round/Plane Surface UV Drying Machine
- Bottle UV Drying Machine
Product Details
Condition: | New | Type: | Other, folder gluer | Automatic Grade: | Automatic |
Place of Origin: | China | Brand Name: | AMC | Model Number: | SG-2400 |
Voltage: | 380V 50HZ | Power(W): | 12 KW | Dimension(L*W*H): | 11000x3000x1600mm |
Weight: | 5.5T | Warranty: | 12 monthes | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
QF AUTOMATIC FOLDER GLUER
Characteristics:
- Belt feeder with vacuum suction
- Frequency convertor control machine speed. PLC control, touch screen operating.
Technical Specification:
Model | QF-2400 | QF2500 |
Max. sheet size | 1200x2400mm | 1200x2500mm |
Min. sheet size | 300x900mm | 300x900mm |
Max. speed | 130m/min | 130m/min |
Max. working speed | 100m/min | 100m/min |
Dimensions (LxWxH) | 11000x3000x1600mm | 12500x3200x1600mm |
Total weight | 5500kg | 6500kg |
Power Required | 12KW, 380V, 3Phase, 50HZ | 12KW, 380V, 3Phase, 50HZ |
Corrugated sheet type | 3-ply / 5-plycorrugated sheet | 3-ply / 5-plycorrugated sheet |
Details of each section
Feeding Section
- Vacuum suction feeding to feed warping paperboard easily
- Quality electromagnetic clutch and brake adpoted, feeding section controlled independently, operation easily
- Stainless steel glue wheel adopted, longworking life and saving glue cost
- Second creasing struction can impress again the paperboard which was not creased well
Gluing and Folding Section
- Simpless structure and high reliability, glue quantity adjustable, cleaning easily
- Creaser wheel adjustable, suit for 2-8mm thick paperboard
- Imported quality rubber belt adopted, automatic folding
- With paperboard rectify device and creasing rectify device
Counter and Stacker Section
- Stacking and counting are simple and reliable
- Digital control, operation easily and reliable. No-stop put in data and automatic counting
- With rectification function
- Paperboard counting and put out by pneumatic, stable and quickly
