TURRET MILLING MACHINE ( SM-6SLB )
- 100 Set / Sets per Month
- SHENZHEN
- T/T
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial CNC Milling Machine, production, Machine Center for steel, stainless
Product Details
Condition: | New | Place of Origin: | Yunnan, China | Brand Name: | SMARTECH |
Model Number: | SM-6SLB | Type: | Universal | CNC or Not: | Normal |
Product Description
Specifications
SMARTECH TURRET MILLING MACHINE SM-6SLBCompetitive price
Good performance
Rigid structure
Precise
- STANDARD ACCESSORIES:
1 Coolant system;
2 Halogen working lamp;
3 Draw bar;
4 Luxury electric control box ;
5 Way rubber cover (front & back);
6 Tool and tool box;
7 English operation manual, packing list and inspection certificate;
8 Power table elevating system;
9 Splash base pan;
- OPNTIONAL ACCESSORIES:
1 SINO digital read out system (2-axis OR 3- axis)
2 Chuck collect set
3 Coolant system
4 Luxury halogen working lamp
5 6 angle lock machine vise
6 58pcs clamping kit set
7 X-axis electric power feed unit
8 Y- axis electric power feed unit
9 3C-1005 X-axis gear type power feed unit
10 3C-1002 Y- axis gear type power feed unit
11 X-axis inverter motor variable feed system
12 Y- axis inverter motor variable feed system
13 Air power draw bar
- SPECS:
MODEL | SM-6SLB |
Slide ways Structure | Y/Z: Square, X axis wide saddle |
Table Size | 1370X330mm |
Travel | X - 1014mm |
Y - 420mm | |
Z - 460mm | |
Quill | 127mm |
Ram | 610mm |
Quill Diameter | 105mm |
Quill Feed Rate | 0.04, 0.08, 0.15mm |
Spindle Motor | 3.75kw (5HP) |
Spindle Taper | NT40 |
Spindle Speed | 10 steps: 60-3600rpm |
Head Tilt Angle | B&F ±45° or fixed, R&L ±90° |
Dist. Table-Spindle | 100-560mm |
Dist. Column-Spindle | 100-710mm |
Machine Weight | 2300kgs |
Dimension | 235X184X255CM |
