cnc machining centre PS-VMC850 VMC Machining centre PS-VMC850 Technical data :
CNC Machinery Centre Table |
Size |
mm |
460*950 |
||
Maximum Load |
Kg |
600 |
|||
T-Slot |
|
3-18H8 |
|||
T-slot Pitch |
mm |
150 |
|||
Machine |
X axis travel |
mm |
800 |
||
Y axis travel |
mm |
500 |
|||
Z axis travel |
mm |
500 |
|||
Distance between spindle nose to the table |
mm |
150-650 |
|||
Distance between axis to column |
mm |
550 |
|||
Spindle |
Spindle Taper |
|
ISO40 |
||
Taper hole of spindle |
|
BT40 |
|||
Power of Spindle(basic configuration) |
kw |
5.5/7.5(servo) |
|||
Power of Spindle(Optional) |
kw |
5(frequency conversion) |
|||
Maximum speed(basic configuration) |
rpm |
8000 |
|||
Maximum speed (Optional) |
rpm |
6000(frequency conversion) |
|||
Maximum speed (Optional) |
rpm |
10000,12000,15000 |
|||
Feed |
Maximum feed speed |
mm/min |
6000 |
||
Rapid feed speed(X/Y/Z) |
mm/min |
12000 |
|||
Ball Screw |
X-axis ball Screw |
mm |
40*8 |
||
Y-axis ball Screw |
mm |
40*8 |
|||
Z-axis ball Screw |
mm |
40*8 |
|||
|
Geometric Precision |
GB/T8771.2-1998 |
||||
Overall Dimensions |
Dimension |
mm |
2300*2300*2500 |
||
Weight |
Kg |
<4500 |
|||
