Specifications
Optical Power Meter ,APM820/830270, 1000, 2000 Hz Tone detection
Optical Power Meter ,APM820/830 Optical Power Meter
270, 1000, 2000 Hz Tone detection;
Insertion loss test in dB;
SM or MM applications;
2.5mm universal and FC, SC, ST, LC;
850/1300/1310/1490/1550/1625nm calibrated wavelengths;
APM820 is for telecom testing, APM830 is for CCTV testing;
Energy save mode: about 10 minutes, no operation will cause the deviceautomatic power off (can be cancelled);
Reference value storage;
Full energy can support above 100 hours operation;
Main Characteristic
| APM820 | APM830 | |
Measuring Range | +8 ~ -70dBm | +26 ~ -50dBm | |
Accuracy * | ± 0.2 dB | ||
Calibrated Wavelengths | 850nm / 1300nm / 1310nm / 1490nm / 1550nm / 1625nm | ||
Display Resolving Power | 0.01dB | ||
Connecting Adaptor | 2.5mm universal and FC, SC, ST; | ||
Reference Value storage | Yes | ||
Automatic Power Off | No operation in 10 minutes (can be cancelled), Low battery energy | ||
Tone Detector ** (optional) | +5 ~ - 40 dBm | +20 ~ - 25 dBm | |
Battery Charge | Yes | ||
Battery Life | Above 100 hours | ||
Storage Temperature | -20 -- +60 °C, 90%RH | ||
Operating Temperature | -10 -- +50 °C, 90%RH | ||
Power Supply | AA * 2 batteries or AC/DC adapter | ||
Size | 140mm * 62mm * 31mm | ||
Weight | About 150g | ||
* at 20±3°C, CW, with FC connector, -10dBm
** at 20±3°C, 1550 nm
Accessories
Standard | Carrying bag | 1 |
User’s manual | 1 | |
Box | 1 | |
Calibration certification | 1 | |
FC, SC, ST connector | 1 for each | |
Optional | AC/DC adapter | 1 |
