Silicon (Si) mirrors
USD $20 - $50
/ Piece
10 Pieces(Min.Order)
- 1000 Piece / Pieces per Month
- Saint-Petersburg
You May Like
Product Details
| Place of Origin | Saint Petersburg, Russian Federation | Brand Name | Alkor Technologies | |
| Model Number | Si-mirror-25.4 | Material | Other, Silicon optical grade | |
| Usage | Infrared | Shape | Plano |
Product Description
Silicon (SI) Mirrors
Coated silicon substrates are most commonly used as mirrors for CO2 lasers. Its advantages are good durability, thermal stability and relatively low cost. The total reflectors are used as rear reflectors and fold mirrors externally as beam benders in beam delivery systems.
Specifications
Material | Si |
Density, g/cm3 | 2,33 |
Surface quality | 60-40 scratch & dig |
Clear aperture | >80% of diameter |
Diameter tolerance | +0.0 -0.1 mm |
Thickness tolerance | ±0.1 mm |
Surface flatness | by request |
Operation wavelength | 10.6 µm |
Coating | protected gold |
Reflectivity for unpolarised radiation | > 99% |
