NaCl (Sodium Chloride) Infrared Window

US$ 20 - 60 MOQ: 3 Pieces

Key Specifications

Place of Origin:

Russian Federation

Material:

Other, NaCl

Usage:

Infrared

Ooo Alkor Technologies

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Russian Federation

Material Other, NaCl

Usage Infrared

Shape Plano

SODIUM CHLORIDE: NaCl windows, NaCl polished crystals. NaCl drilled discs.

Excellent Transmission from 250nm – 16µm
Low Cost
Ideal for FTIR Spectroscopy
Drilled windows available
Packing: All NaCl optics carefully packaged into plastic boxes with silicagel and sealed with special moisture protective film.

Cat#	Dia, in	Dia,mm	TH, in	TH, mm
NC-W-12.7-2	0.5	12.7	0.079	2.0
NC-W-12.7-3	0.5	12.7	0.079	3.0
NC-W-25.4-2	1	25.4	0.079	2.0
NC-W-25.4-3	1	25.4	0.118	3.0
NC-W-25.4-4	1	25.4	0.157	4.0
NC-W-25.4-5	1	25.4	0.197	5.0
NC-W-25.4-6	1	25.4	0.236	6.0
NC-W-30-4	1.18	30	0.157	4
NaCl-W-32x3-Drilled*	1.26	32	0.118	3
NC-W-38.1-3	1.5	38.1	0.118	3.0
NC-W-38.1-4	1.5	38.1	0.157	4.0
NC-W-38.1-5	1.5	38.1	0.197	5.0
NC-W-38.1-6	1.5	38.1	0.236	6.0
NC-W-38.5x19.5x4	1.515x0.768	38.5x19.5	0.157	4.0
NC-W-45x20x6	1.772x0.787	45x20	0.236	6
NC-W-40-10	1.575	40	0.394	10.0
NC-W-50.8-1	2	50.8	0.039	1.0
NC-W-50.8-4	2	50.8	0.157	4.0
NC-W-50.8-5	2	50.8	0.197	5.0
NC-W-50-6	2	50.8	0.236	6.0
NC-W-63.5-6	2.5	63.5	0.236	6.0
NC-W-63.5-8	2.5	63.5	0.315	8.0
NC-W-76.2-8	3	76.2	0.315	8.0
NC-W-76.2-12	3	76.2	0.472	12.0
Custom NaCl windows up to 110mm diameter are available upon request. * - minimal order for drilled windows - 10pcs

NaCl windows: Standard Specifications
Material	NaCl optical grade
Dimensions	± 0.00/-0.10mm
Thickness	± 0.10mm
Surfaces	S/D: 80/50 (up to 40/20 on small diameters)
Edges	Fine Ground
Flatness	By request (up to 0.5 fringe on half inch diameter)
Parallelism	≤ 3 Arc mins
