Api 5CT Standard 7K Oil Drill Hydraulic Tubing Power Tong

Negotiable MOQ: 20 Tons (Price negotiable depending on order volume and customization)

Key Specifications

Standard:

Thickness:

19.15, 26.15

Section Shape:

Round

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Thickness 19.15, 26.15

Section Shape Round

Outer Diameter 88.9 - 114.3 mm

Place of Origin China

Secondary Or Not Non-secondary

Application Other, oil tubing

Technique Hot Rolled

Certification API

Surface Treatment Copper Coated

Special Pipe API Pipe

Alloy Or Not Is Alloy

Specifications

1.Has the heat-proof performance
2.Size:88.9mm~114.3mm

1.Has the heat-proof performance
2.Size:88.9mm~114.3mm
3.The main is body pipe string,hest insulation layer,coupling,seals etc

Basic Parameter				Main Performance Parameter							Working Parameter
OD (mm)	ID (mm)	OD of coupling (mm)	Coupling thread	Apparent coefficient of heat conductivity (inner thickness at 350°C) W/m·°C	Tension load at normal temperature (kN)	Resistance of Internal pressure (MPa)		Resistance of external pressure (MPa)		Flatness (%)	Well depth (m)	Temperature °C		Fixed casing in(mm)
						Resistance of Internal pressure (MPa)		Resistance of external pressure (MPa)				Normal Working Time	Overheat (3~4h)
						Normal temperature	Steam injection	Normal temperature	Steam injection			Normal Working Time	Overheat (3~4h)
88.9	50.6	108	3-1/2USS	0.02~0.08	432	32	20	30	28	≤0.2	≤1500	350	380	5 (139.7)
88.9	40.9	108	3-1/2USS	0.02~0.08	402	32	20	30	28	≤0.2	≤1500	350	380	5 (139.7)
127.0	76.0	141.3	5BCSG	0.02~0.08	615	32	20	23	21	≤0.2	≤1500	350	380	9 5/8” (244.5)
114.3	76.0	127.0	4 1/2 CSG	0~0.08	537	32	20	26	24	≤0.2	≤1500	350	380	7” (177.8)
114.3	62.0	127.0	4 1/2 CSG	0~0.08	506	32	20	26	24	≤0.2	≤1500	350	380	7”
