130T PET Preform Variable Pump Injection Molding Machine

130T PET Preform Variable Pump Injection Molding Machine thumbnail-1
130T PET Preform Variable Pump Injection Molding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Horizontal
Contact Supplier Request Quote Chat Now
Foshan Powerjet Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangdong Ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Preform Injection
Style Horizontal
Brand Name Powerjet
Model Number PET-350V6
Place of Origin Guangdong, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 387g
Clamping Force 130T
Opening Stroke 350mm
Power(W) 11+10KW
Certification CE/ISO9001
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.PET specially made screw
2.CE/ISO9001 approved
3.Different models are available
4.Whole production line can be provided





Technical Parameter of PET-350V6
Description Unit PET-350V6
    HPET-350V6
Injection Unit
Screw Diameter mm 46
Screw L/D Ratio   22
Shot Volume cm3 333
Shot Weight(@PS1.05) g 313
Shot weight(@PET1.3) g 387
Shot weight(@PP0.9) g 268
Injection Pressure Mpa 125
Screw stroke mm 200
Max.screw rotary speed rpm 180
Clamping Unit
Clamping Force KN 1300
Opening Stroke mm 350
Max daylight: mm 750
Space between Bars(H*V) mm*mm 410x410
Movable platen size(H*V) mm*mm 610x610
Max. Mold Height mm 400
Min. Mold Height mm 145
Ejector Stroke mm 100
Ejector Force KN 60
Ejector-back force KN 36
Number of ejector pins   4+1
Power Unit
Hydraulic System Pressure Mpa 17.5
Pump Motor Power KW 11
Heater Power KW 10
Total current A 65
General
Oil Tank Capacity L 200
Machine Weight Ton 3.6
Machine Dimensions(L*W*H) m*m*m 4.5x1.2x1.8

*  H series can achieve press holding and material charge at the same time, suitable

for the mold with better cooling system, shortening the cycle time.



130T PET Preform Variable Pump Injection Molding Machine



Main Characteristic

  • Specially made PET screw highly increases he plasticizing speed and shot weight, lowers the plasticizing speed and temperature and AA value, also lowers the shearing of perform, while achieves better transparency.

       130T PET Preform Variable Pump Injection Molding Machine

  • The servo motor control system can save energy by 30%-60%, while the variable pump control system can save energy 25%-45%.
  • Different models are available for the choice of customers.
  • Increasing eject force ejector stroke, accepts PET perform molding.
  • Whole closed safe door meets the requirement of sanitary and thermo-control.
  • Hot runner system interface is included.130T PET Preform Variable Pump Injection Molding Machine
  • Optional with pressure holding and charge at the same time, which can increase the output by 15%-25%.
  • Whole production project can be provided,including moulds,injection molding machine,PET stretch blow molding machine and auxiliary equipmnts.
