130T CE Approved Energy-saving Double Colors Injection Moulding Machine With Servo Motor

130T CE Approved Energy-saving Double Colors Injection Moulding Machine With Servo Motor thumbnail-1
130T CE Approved Energy-saving Double Colors Injection Moulding Machine With Servo Motor photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Tube Head Injection
Style:
Horizontal
Contact Supplier Request Quote Chat Now
Foshan Powerjet Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tube Head Injection
Style Horizontal
Brand Name Powerjet
Model Number BJM130S5
Place of Origin Guangdong, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 60-90g
Injection Rate 64-84g/sec
Clamping Force 1300KN
Opening Stroke 400mm

Specifications

1.Energy-saving
2.Excellent performence
3.Reducing production costs
4.Easy operating
5.2 materials/double colour injection

Features



lUsing servo pump hydraulic system to lower power consumption,

lFaster response, higher repetition, better stability.

lInjection molding with 2 materials or double colors at the same time, which can reduce the cost of the technology and the human resources.

lVery easy to set parameters and adjust hydraulic system with the digit control.



Working Principle



The injection molding machine injects the first material into the mould and the plastic takes the shape. After the mould is open, the movable ratary mould platen turns around with the other work pieces by 180° then the machine makes the second injection after the injection nozzles is directed at the cavities of the mould and the mould is closed, and then finally takes shape. Or the first material injection and the second material can be done at the same time to take shape.





                                               PARAMETER OF BJM130S5
DESCRIPTION UNIT BJM130S5
CLAMPING UNIT
Clamping force KN 1300
Opening stroke mm 400
Max.daylight mm 850
Platen size mm×mm 1060×800
Space between Bars(H*V) mm×mm 720×410
Max. Mold Height mm 450
Min. Mold Height mm 130
Ejector Stoke mm 120
Ejector Force KN 2×49
INJECTION UNIT A B
Screw Diameter mm 26 28 30 26 28 30
Screw L/D Ratio   22.6 21 19.6 22.6 21 19.6
Injection Pressure Mpa 234 202 155 234 202 155
Shot Volume cm³ 63 73 96 63 73 96
Shot Weight(PS) g 60 69 90 60 69 90
OZ 2.0 2.4 3.2 2.0 2.4 3.2
Injection rate g/sec 64 73 84 64 73 84
Screw Stroke mm 120 120
Screw Speed RPM 230 230
POWER UNIT
Hydraulic system pressure MPa 16
Pump motor power KW 11+11
Heater power KW 7
GENERAL
Oil tank capacity L 210
Machine weight Ton 6
Machine dimensions(l×w×h) m×m×m 5×1.6×1.8
