High Quality SMT Technology Smart Card Water Meter

Application

Measuring the volume of portable water that through the pipeline. Widely used in residential area and office building

Working Conditions
Water temperature (cold water): ≤ 40℃
Water temperature (hot water): ≤ 90 ℃
Water pressure: ≤ 1.6 Mpa
Construction
This meter consists of a meter body, a measuring unit, a register unit, a lens and others.
Indication
Cubic meter (m 3) and U.S.gallon(USG) for selecting.

◆Valve will shut down for warning when the remaining water is less than the warning limitation, and the valve will open up when inserting the card; Valve will termly shut down and open up automatically to prevent rust;

◆Hall sensor sampling, anti-magnetic attack with agile switching.

◆The data will be saved even if the power is cut;

◆External battery placement, easy to replace and its life is more than 6 years.

◆Patent ball valve, low pressure loss;

◆The entire water supply system is effectively controllable through mode of free record and pre-payment water fees;

◆The system saves a lot of manpower, and accelerates cash flow, helps to control the non-recoverable charges and do away with the due payment;

◆Quota use volume, lays down a flight of stairs water expenses, promotes water saving by using of pricing lever.
